Regency Ceiling Fans Akina Owner's Manual page 8

i
nstalling the
WARNING:
To avoid damaging the blade arms and blades, do not install them onto fan until fan is fastened to ceiling.
1. Lift ball/downrod/fan into hanging bracket opening.
NOTE: The tab opposite hanging bracket opening should
fit in slot on ball (Fig. 1).
2. Make wire connections, (refer to page 7 "Electrical Connections").
3. Slide canopy up and fasten to hanging bracket with 2 screws provided, make sure receiver is inside of canopy (Fig. 2).
4. Slide canopy screw cover plate up to canopy and attach to screws. Align slots with screw heads and twist on to lock
in place (Fig.2).
F
an COntinued
Hanging
bracket
tab
Ball slot
Ball
6
Receiver
Canopy
Hanging bracket
Screws
Canopy Screw
cover Plate
