Summary of Contents for Regency Ceiling Fans Strasburg
- Page 1 Style that revolves around you. ’ • • EILING WNER ANUAL • S • TRASBURG 11/05 WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
- Page 2 & O ENERAL NSTALLATION PERATION NSTRUCTIONS MPORTANT AFEGUARDS 1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning. 2. To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring. All electrical connections must be made in accordance with local codes, ordinances and/or the National Electric Code.
- Page 3 MPORTANT AFETY RECAUTIONS Thank you for choosing a Regency Ceiling Fan. You have chosen the best! Your new ceiling fan has been designed to provide many years of service and enjoyment. Warnings: • Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional lighting.
- Page 4 NPACKING 1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary, the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side, or the decorative housing may shift, be bent or damaged.
- Page 5 REPARATION Parts identification on assembled fan Canopy Downrod Fan Housing Glass Shade Blade Blade Arm REPARATION Verify you have all parts before beginning the installation. Check foam insert closely for missing parts. Remove motor from packing. To avoid damage to finish, assemble motor on soft padded surface or use the original foam inset in motor box.
- Page 6 NSTALLING THE 1. Carefully support fan housing (motor) in its styrofoam packing with the mounting collar (where the wires come out) facing upward. 2. Remove ball from downrod by loosening set screw in the side of the ball. Slide ball down and remove ball pin; remove ball.
- Page 7 NSTALLING ANGING THE FAN WARNING: To avoid damaging the blade arms and blades, do not install them onto fan until fan is fastened to ceiling. 1. Lift ball/downrod/fan into hanging bracket opening. NOTE: The tab opposite hanging bracket opening should fit in slot on ball.
- Page 8 EMOTE ONTROL ENERAL NFORMATION Multiple code choices are included with your fan’ s remote control in case: • you have more than one remote control fan and want them to respond only to their own remote control • you have other radio controlled devices in your home that may interfere with the fan remote control (i.e. garage door opener) •...
- Page 9 LECTRICAL ONNECTIONS Be sure electricity is turned off at the main power box before wiring.* Five wires are connected to the fan Black - the “hot” power to run fan. White - the “common” power to run fan and light, also referred to as “AC neutral”.
- Page 10 & B LADE LADE TTACHMENT 1. Place washer on screw. Insert this assembly through the blade and start Screw the screw into the blade arm. Repeat this procedure without tightening the Washer screw until all 3 screws have been started into the blade arm (Fig. 1). 2.
- Page 11 NSTALLATION OF ETACHABLE WITCH OUSING NOTE: Be sure to turn of the power before installing. 1. If installing a light kit, attach to switch housing per instructions supplied with light kit. See “Electrical Connections” for hook-up of light kit. Carefully remove kit plug in bottom of switch housing. 2.
- Page 12 PERATION PERATING BUTTONS ON THE RANSMITTER HI – fan high speed MED – fan medium speed LOW – fan low speed FAN/OFF – fan speed off LIGHT – light brightness and off function for uplight, and one for downlight FOR/REV – forward and reverse •...
- Page 13 ARE AND LEANING Periodic cleaning of your new ceiling fan is about the only maintenance that is needed. Only use a soft brush or lint free cloth to avoid scratching the finish. DO NOT use water when cleaning your ceiling fan. It could damage the motor or the wood blades, and/or create the possibility of electrical shock.
- Page 14 HANK YOU FOR PURCHASING A EGENCY EILING Write to us at: Regency Ceiling Fans P.O. Box 730 Fenton, MO 63026 For additional troubleshooting tips, visit us on the Web at: www.regencyfan.com 11/05 Regency Ceiling Fans...
