Summary of Contents for Regency Ceiling Fans Amani
- Page 1 ’ • • EILING WNER ANUAL • A • MANI 1/07 WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
- Page 2 & O ENERAL NSTALLATION PERATION NSTRUCTIONS MPORTANT AFEGUARDS 1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning. 2. To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring. All electrical connections must be made in accordance with local codes, ordinances and/or the National Electric Code.
-
Page 3: Important Safety Precautions
MPORTANT AFETY RECAUTIONS Thank you for choosing a Regency Ceiling Fan. You have chosen the best! Your new ceiling fan has been designed to provide many years of service and enjoyment. Warnings: • Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional lighting. - Page 4 NPACKING 1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary, the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side, or the decorative housing may shift, be bent or damaged.
- Page 5 REPARATION Parts Downrod Uplights (on top identification Decorative Wire Supports of fan motor Collar Cover housing) assembled Blade Motor Housing Blade REPARATION Verify you have all parts before beginning the installation. Check foam insert closely for missing parts. Remove motor from packing.
- Page 6 NSTALLING OTOR SSEMBLY 1. Place the motor assembly on a stable flat surface with the wire lead end facing up. 2. With the motor sitting upright, place the glass support frame onto the support flange of the motor housing assembly. 3.
- Page 7 NSTALLING THE ANG THE FAN 1. Lift ball/downrod/fan into hanging bracket opening. NOTE: The tab opposite hanger bracket opening should fit in slot on ball. 2. Make wire connections, (refer to section titled “Electrical Connections”). 3. Slide canopy up and fasten to hanging bracket with 2 screws provided. Hanger bracket Ball slot...
-
Page 8: Electrical Connections
LECTRICAL ONNECTIONS Be sure electricity is turned off at the main power box before wiring.* Four wires are connected to the fan (plus the ground wire). Black - the “hot” power to run fan. White - the “common” power to run fan and light, also referred to as “AC neutral”. -
Page 9: Blade Attachment
LADE TTACHMENT LADE TO LADE TTACHMENT 1. Place washer on screw. Insert this assembly through the blade and start the screw into the blade arm. Repeat this procedure without tightening the screw until all 3 screws have been started into the blade arm (Fig. -
Page 10: Housing Assembly
WITCH OUSING SSEMBLY 1. With the blade arms attached to the fan, you can attach the switch housing. 2. Loosen two of the three screws located on the mounting hub and remove the third. 3. Feed the light wires through the switch housing. 4. - Page 11 NSTALLATION OF IGHT PTION 1. With the fan body installed to the ceiling, remove the switch housing cover from the packing. 2. The cover will have three mounting holes in it unlike the access cover which has a threaded pipe. 3.
-
Page 12: Installation
OMPLETING THE NSTALLATION 1. Install 4 candelabra base bulbs (E12, 25 watt maximum) into sockets on top of fan body. 2. Screw decorative wire support into metal frame of fan body. 3. Hook decorative wire support into corresponding loop on bracket. 4. -
Page 13: Remote Control
EMOTE ONTROL ENERAL NFORMATION Multiple code choices are included with your fan’ s remote control in case: • you have more than one remote control fan and want them to respond only to their own remote control • you have other radio controlled devices in your home that may interfere with the fan remote control (i.e. garage door opener) •... -
Page 14: Operation
PERATION PERATING BUTTONS ON THE RANSMITTER HI – fan high speed MED – fan medium speed LOW – fan low speed FAN/OFF – fan speed off LIGHT – light brightness and off function for uplight FOR/REV – forward and reverse •... -
Page 15: Troubleshooting
ROUBLESHOOTING ASE OF IFFICULTY IMPORTANT: To prevent damage or cause injury, be sure that fan is switched to off and blades have stopped moving completely before attempting to change direction of rotation. 1. If fan will not start: Check main and branch circuit breakers and/or fuses. Check line wire connections to fan and switch housing wiring. - Page 16 HANK YOU FOR PURCHASING A EGENCY EILING Write to us at: Regency Ceiling Fans P.O. Box 730 Fenton, MO 63026 For additional troubleshooting tips, visit us on the Web at: www.regencyfan.com 1/07 Regency Ceiling Fans...
