PART IDENTIFICATION CHART

Use the drawings below to identify small parts used in assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key
number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it has
been preattached.
M8 Locknut M8 Star
Wave Washer M8 x 25mm
Washer (122)––4
(102)––4
(95)––4 Washer (98)––6
#8 x 1/2" #8 x 3/4" M6 x 10mm M8 x 16mm M8 x 19mm
Screw (124)––4 Screw (123)––11 Screw (121)––8 Screw (120)––6 Screw (82)––4
M8 x 35mm M10 x 75mm
Bolt (96)––4 Screw (119)––2
M10 x 90mm
Screw (84)––2
