KTM 690 DUKE EU Owner's Manual page 172

TECHNICAL DATA - CHASSIS TIGHTENING TORQUES
Screw, foot brake cylinder
Screw, fuel tap
Screw, headlight mask
Screw, horn
Screw, license plate holder
Screw, lower radiator bracket
Screw, magnetic holder on side stand
Screw, side stand bracket
Screw, SLS valve
Screw, voltage regulator
Nut, manifold on cylinder head
Nut, rear sprocket screw
Remaining nuts, chassis
Remaining screws, chassis
Screw, bottom triple clamp
Screw, fork stub
Screw, front brake disc
Screw, fuel tank bracket
Screw, handlebar clamp
Screw, handrail
Screw, ignition lock
Screw, linkage bracket, front engine
bracket
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
10 Nm (7.4 lbf ft)
Tightening sequence:
tighten in parallel
6 Nm (4.4 lbf ft)
5 Nm (3.7 lbf ft)
6 Nm (4.4 lbf ft)
8 Nm (5.9 lbf ft)
5 Nm (3.7 lbf ft)
12 Nm (8.9 lbf ft)
10 Nm (7.4 lbf ft)
6 Nm (4.4 lbf ft)
8 Nm (5.9 lbf ft)
25 Nm (18.4 lbf ft)
35 Nm (25.8 lbf ft)
30 Nm (22.1 lbf ft)
25 Nm (18.4 lbf ft)
15 Nm (11.1 lbf ft)
15 Nm (11.1 lbf ft)
30 Nm (22.1 lbf ft)
15 Nm (11.1 lbf ft)
20 Nm (14.8 lbf ft)
6 Nm (4.4 lbf ft)
25 Nm (18.4 lbf ft)
170
®
Loctite 243™
–
–
®
Loctite 243™
–
–
®
Loctite 243™
®
Loctite 243™
–
–
Copper paste
®
Loctite 243™
–
–
–
–
®
Loctite 243™
–
–
–
®
Loctite 243™
®
Loctite 243™
