Preparing For Installation; Audience; Documentation Resources; Kit Description - HP Cluster Platform Hardware Kits v2010 Installation Manual

1 Preparing for Installation

1.1 Audience

This guide is intended for HP service representatives and other persons trained to install hardware
options in the HP 10000 series racks. Such persons are expected to understand the hazards of
working in this environment and to take suitable precautions to minimize danger to themselves
and others.

1.2 Documentation Resources

You can download the documentation for components referenced in this installation guide from
the following locations or access specific manuals and guides from the CD that is shipped with
your HP Cluster Platform solution:
HP 10K Series Rack (Documentation
option):
HP Cluster Platform:
HP ProCurve Networking:

1.3 Kit Description

The cable management brackets described in this manual are designed to align and support
cables that lead from an HP ProCurve 5406zl system interconnect to the PCI interface cards
installed in each server (node). The brackets provide strain relief, ensure the correct bend radius
for the cables, and provide cable routing and cable management.

1.4 Kit Contents

This kit contains the following components:
• The cable management brackets shown in
Figure 1-1 Cable Management Brackets
The following list describes the callouts shown in
http://h18004.www1.hp.com/products/servers/proliantstorage/racks
http://www.hp.com/techservers/clusters/xc_clusters.html
http://www.hp.com/rnd/products/index.htm
Cluster Platform Gigabit Ethernet Interconnect Guide
Figure 1-1.
2
1
Figure 1-1:
