Required Resources - HP Cluster Platform Hardware Kits v2010 Installation Manual

Table 1-1 Fastener Specifications
Qty. Size
2 10-32 x .375-inch
4 M6 x 16 mm
4 M6
2 10-32
• Packaging and documentation.
To prevent screws from becoming loose due to vibration, HP recommends using an adjustable
torque driver set to the torque specifications given in
representative if any parts are missing from your kit.

1.6 Required Resources

To install the generic cable management bracket kit, you need the following resources:
• Tools:
— A 6-inch long #2 (medium) Phillips (Posidrive or cross-point) screwdriver, or #2 bit for
a power screwdriver.
— Cage-nut insertion tool (optional).
— Marker pen or masking tape.
• Resources: A sample cable of the type used by the system interconnect.
• Environment:
— A work surface adjacent to the rack.
— A stable work platform or step stool that lets you safely reach the servers installed in
the upper part of the rack.
8 Preparing for Installation
Format Torque
Phillips 30 in/lb
(Posidrive)
Phillips 30 in/lb
(Posidrive)
Square nut N/A
Square nut N/A
Description
Machine screw, pan-head. For use with a threaded
insert in the server's rail kit, or the 10-32 cage nuts.
Machine screw, pan-head. For use with the cage nut.
Cage nut for M6 x 16-mm screw.
Cage nut for 10-32 x .375-inch screw.
Table 1-1. Contact your HP sales
