Figure 1-1 Cable Management Brackets
The following list corresponds to the callouts shown in
1. Cable management bracket – right side
2. Cable management bracket – left side
3. Right side cable management bracket top and side views (left side cable management
bracket opposite).
• The fasteners that are specified in
Table 1-1 Fasteners
Qty. Size
4 M6 cage nuts
4 M6 x 16mm
screws
• Packaging and documentation.
To prevent screws from becoming loose because of vibration, HP recommends that you use an
adjustable torque driver set to the torque specifications given in
representative if any parts are missing.

1.5 Required Resources

To install the kit, you require the following resources:
• Tools:
— Screwdriver, #2 (medium) Phillips.
— Cage-nut insertion tool (shipped with the rack) or a flat-bladed screwdriver.
— Marker pen or masking tape.
• Resources: A sample cable of the type used by the system interconnect.
• Environment:
10 Preparing for Installation
1
2
Format
Square nut
Phillips
(Posidrive)
Figure
Table 1-1.
Torque Description
N/A Cage nut for M6 x 16mm screw.
30 in/lb Machine screw, Phillips head. For use with the cage
nut.
3
1-1.
Table 1-1. Contact your HP sales
