- Page 1 AU-11DM Universal Digital/Analogue Audio Converter with Dolby Digital Decoder OPERATION MANUAL...
-
Page 2: Safety Precautions
Safety Precautions Please read all instructions carefully before installing or operating this product. Always follow basic safety precautions to reduce the risk of fire, electrical shocks and injuries. To prevent fires or shocks do not expose this product to rain, moisture or install it near water. -
Page 3: Table Of Contents
Table of Contents 1. Introduction .................... 1 2. Applications ................... 1 3. Package Contents ................1 4. System Requirements ................1 5. Features ....................1 6. Specifications ..................2 6.1 Input Audio Reference Level ............2 6.2 Input Audio with Output Audio Comparison Chart ....2 Operation Controls and Functions ............ -
Page 4: Introduction
1. Introduction The Universal Digital/Analog Audio Converter with Dolby Digital Decoder is a gadget that can convert Optical, Coaxial and L/R audio signals with output sound guarranty. With the ability to convert digital signals into analog and analog signals into digital, this gadget supports the simultaneous conversion of audio formats so when you are converting Optical into L/R audio you can also convert it into Coaxial and enjoy it without pop sound or suddend disappear. -
Page 5: Specifications
6. Specifications Input Ports Optical, Coaxial and L/R Input Format LPCM 2CH and Dolby Digital from Optical/Coaxial Sample Frequency 32kHz, 96kHz Output Ports Coaxial, Optical and L/R L/R Input Impedance 47K Ω L/R Output Impedance 600 Ω ESD Protection Human body model: ± 10kV (air-gap discharge) ±... -
Page 6: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Top Panel UNIVERSAL Dolby DIGITAL / ANALOG AUDIO CONVERTER POWER L/R COAX OPTICAL ① ② ③ ④ ⑤ ① When the device is turned on the LED is green, and when turned off the devices LED is red. -
Page 7: Right Panel
7.2 Right Panel OPTICAL COAX ① ② ③ ① OPTICAL: The audio sources optical cable connects here. ② COAX: Connect audio sources Coaxial cable in this socket. ③ L/R: This is where you insert the audio sources L/R cable. 7.3 Left Panel COAX OPTICAL ①... -
Page 8: Connection And Installation
8. Connection and Installation... -
Page 9: Acronyms
