Summary of Contents for CYP AU-11SA-4K22
- Page 1 AU-11SA-4K22 CPLUS-V11SE8 UHD 4K 6G with HDCP2.2 LPCM 7.1 Audio Extractor Operation Manual Operation Manual...
- Page 2 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fi re, electrical shock and injury to persons.
-
Page 3: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..2 6.1 Front Panel ........2 6.2 Rear Panel .........3 7. Connection Diagram ......4 8. -
Page 4: Introduction
1. INTRODUCTION The HDMI 4K 6G LPCM 7.1 Channel Audio Extractor could extract audio signals from your HDMI source. The unit allows you to extract original HDMI audio signal and convert it to digital optical or analog multi-channel audio. Further, both input and output HDMI support UHD resolution up to 4K2K@60Hz (YUV444), and capable of provide high quality of audio and video performance. -
Page 5: Features
5. FEATURES • HDMI2.0 with 4Kx2K 6G supported, HDCP 2.2 and DVI compliant • Supports HDMI audio sampling rate up to 192 kHz • Supports Optical S/PDIF audio sampling rate up to 192 kHz • Supports external HDMI, Digital or Analog audio signal embeds into HDMI •... -
Page 6: Rear Panel
6.2 Rear Panel AUDIO OUT HDMI IN HDMI OUT SERVICE DC 5V OPTICAL HDMI IN: This slot is to connect with source equipment such as Blu- ray/PS3 player or PC/laptop with HDMI signal sending. HDMI OUT: Connect to HDMI UHD TV/display or UHD Amplifi er for output image and or audio display. -
Page 7: Connection Diagram
7. CONNECTION DIAGRAM DVD or Blu-ray Player HDMI Input Power Supply AUDIO OUT HDMI IN HDMI OUT SERVICE DC 5V OPTICAL Digital Optical Audio Output Multichannel Audio Output AV Receiver HDMI Output 7.1 Channels Active Speaker System... -
Page 8: Specifications
8. SPECIFICATIONS Video Bandwidth 600 MHz/6 Gbps Input Ports 1×HDMI, 1×Mini-USB (Service only) Output Port 1×HDMI, 1×Optical, 8×RCA (Analog Audio) HDMI Resolutions VGA~WUXGA (RB), 408i~1080p@24/50/60, 4K@24/25/30, 4K@50/60 (YUV444) HDMI Audio Sampling Up to 192 kHz Rates Optical Audio (S/PDIF) Up to 192 kHz Sampling Rates HDMI Audio Formats LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH,... -
Page 9: Acronyms
Operating Temperature 0˚C~40˚C/32˚F~104˚F Storage Temperature −20˚C~60˚C/−4˚F~140˚F Relative Humidity 20~90% RH (non-condensing) Power Consumption 3.42 W Note: HDMI cable distance might affected by material or design of cable. 9. ACRONYMS ACRONYM COMPLETE TERM Consumer Electronics Control COAX Coaxial Digital Theater System Digital Visual Interface HDCP High-bandwidth Digital Content Protection...
