CYP AU-D250 Operation Manual

Advanced dac with hdmi bypass and audio breakout
Hide thumbs Also See for AU-D250:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
AU-D250
Advanced DAC with HDMI Bypass
and Audio Breakout
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AU-D250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CYP AU-D250

Summary of Contents for CYP AU-D250

  • Page 1 AU-D250 Advanced DAC with HDMI Bypass and Audio Breakout OPERATION MANUAL...

  • Page 2: Safety Precautions

    Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment:  Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.

  • Page 3: Table Of Contents

    Table of Contents 1.Introduction ...............1 2.Applications ..............1 3.Package Contents ............1 4.System Requirements ............1 5. Features ................2 6. Specifications ..............2 7. Operation Controls and Functions .........3 7.1 Front Panel ..............3 7.2 Rear Panel ..............4 7.3 Top Panel ..............5 8. Remote Control ..............5 9.

  • Page 4: Introduction

    1.Introduction The HD Audio Center is an excellent device for converting digital and analog sources. This device allows for simultaneous conversion of a digital or an analog audio input to all digital and analog audio outputs. Featuring a sampling rate converter to 44.1KHz ~ 192KHz (up to 24 bits) output this device also supports 2CH PCM audio, HDMI™, USB Audio 2.0, Optical and Coaxial digital input/output.

  • Page 5: Features

    5. Features Digital • Support 2 Channels PCM HDMI, USB Audio 2.0, Optical, and Coaxial digital interface input / output • All digital interface sampling rate up to 192KHz, and resolution up to 24Bits • All digital interface can be SRC(Sampling Rate Converter) to 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz or 192KHz output •...

  • Page 6: Operation Controls And Functions

    7. Operation Controls and Functions 7.1 Front Panel MENU ①. 6.5mm Phone Jack: This slot is to connect with 6.5mm professional headphone set for user to enjoy the individual professional audio sound. ②. 3.5mm Front IN: This slot is to connect with 3.5Ø phone jack cable from any audio equipment for stereo input audio signal.

  • Page 7: Rear Panel

    7.2 Rear Panel ①. DC 5V: This slot is to connect the power adaptor included in the package and connected from the AC wall outlet for power supply. ②. HDMI IN/OUT: These slots are to connect with HDMI input source equipment such as DVD/ Blu-ray player with HDMI signal sending and output to HDTV/monitor for output image display with HDMI cables.

  • Page 8: Top Panel

    7.3 Top Panel ①. Power button & LED: Press this button to switch on the device or set it to standby mode. The red LED will illuminate when the device is connected with power supply and will turn green if turn on the device. ②. MUTE button: Press this button to mute or unmute the audio volume instantly.

  • Page 9: Osd Menu

    9. OSD MENU Layer Layer Source Selection HDMI In USB In Optical In Coaxial In Line In Front In Return SRC Set Bypass 192 KHz 176.4 KHz 96 KHz 88.2 KHz 48KHz 44.1 KHz Return HDMI TX Set Bypass Input Return Display Set TimeOut 5s...

  • Page 10: Connection And Installation

    10. Connection and Installation...
  • Page 11 Acronyms Acronym Complete Term COAX. Coaxial High Definition HDMI High Definition Multimedia Interface OPT. Optical...
  • Page 12 www.cie-group.com...
