8 Setting USER area

When USER is selected for the AREA of the automatic shutter or for AWB, the light measurement zones
can be changed.
The USER area is composed of 64 zones with 8 (vertical) x 8 (horizontal) areas, and each area can be set
to ON/OFF.
Set the output to area menu.
Set the output to the area menu by referring to the item "7.2 (1.1) (e) Confirming the contents of the
measurement light area selected by automatic shutter" and "7.2 (3.1) (e) Confirming the contents of the
measurement light area selected by AWB".
(blinking)
Move the (blinking) to the zone to be appeared.
The display (blinking) moves up, down, right and left by pushing [MENU UP], [MENU DOWN],
[DATA UP], [DATA DOWN] buttons.
Move to left [DATA DOWN]
Select ON/OFF for the zone.
Select ON (effective) or OFF (ineffective) by pushing [PAGE] button.
When ON is selected, the display " " appears on the screen and when OFF is selected, " " turns off.
Push [DISP] button to return to the menu.
Note:
When OFF is selected for all 64 zones, the automatic shutter function and AWB function are not
performed correctly. So do not select OFF for all.
Move to up
[MENU UP]
[DATA UP]
[MENU DOWN]
Move to down
31
Move to right
