6 SYNC

When an external sync signal is input, the display changes from INT (internal sync) to EXT.(external sync)
automatically.
6 1 INT screen
-- 6 SYNC --
MODE
6 2 Changing EXT. setting
Move up and down
by pushing
MENU UP,DOWN
-- 6 SYNC --
MODE
H PHASE
(a) Adjusting horizontal phase
Move the " " to H PHASE by pushing [MENU UP], [MENU DOWN] buttons.
Select the desired value of horizontal phase by pushing [DATA UP], [DATA DOWN] buttons.
1024
* If the phase difference is big, keep pressing [DATA UP]/[DATA DOWN] button for a while.
This will make the setting change by increments of ten.
INT EXT
<FILE A>
INT
Select the desired
value by pushing
DATA UP,DOWN
<FILE A>
EXT
0
DATA UP
0
DATA DOWN
28
Sync system display
H PHASE -1024 to 1023
1023
