1) Interfaces

Power input: DC 12V, 500mA

WAN: RJ45 port

PC: RJ45 port

EXT: RJ45 port

Headset jack 1 : RJ9 port

Handset jack 1 : RJ9 port


2) Hardware

LCD: 128×64 dot matrix

FLASH: 8M

RAM: 32M

CPU: 262MHz Dual Core

LED indicator: 1 Status Light , 4 line indicators, 9 BLF indicators, 1 voicemail indicator, 1

headset indicator, 1 mute indicator, 1 hand-free indicator
Expander board: 20 BLF keys on each expander board, can connect at most 5

expander boards on a AT840.

3) Software

Sip 2.0 (RFC3261) and other related SIP RFCs

4 SIP lines

Multi-language

G.711A/u, G722, G.723, G.726, G.729 , Lin16-16, iLBC Codec

DTMF inband, RFC2833 and SIP info

Call Forward, DND(Do Not Disturb), Pickup, Redial, Call Park, Call waiting

Call transfer, Call hold, 3-way conference

BLF, SMS, Blacklists, Dial plan, IP to IP call

Auto answer, Block Anonymous call, Block Call-ID

STUN, SNTP

Jitter Buffer,VAD,CNG

HD voice

G.168 compliant 96ms echo cancellation

SIP UDP,TCP, TLS

Phone book with 200 records, 200 answered calls, 200 missed calls, 200 dialed calls

Auto update via HTTP, FTP, TFTP

Syslog

Soft button: soft button * 4

