- Page 1 ® 1:4 DVI Distribution Amplifier EXT-DVI-144N U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth, CA 91311 support@gefen.com www.gefen.com Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. is a trademark of Gefen, LLC 1:4 DVI Distribution Amplifi er All trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction / Operation Notes Features Panel Descriptions Connecting and Operating the 1:4 DVI Distribution Amplifi er Rack Ears Installation Diagram Specifi cations Warranty... -
Page 4: Introduction / Operation Notes
INTRODUCTION Gefen’s 1:4 DVI Distribution is a distribution hub that sends the same DVI graphics source to up to four DVI digital displays (fl at panels or projectors). It is a reliable solution that accommodates four digital video displays at the same time, creating a multi-viewing environment that maintains the highest resolution video at all times. -
Page 5: Features
FEATURES Features • Connects computers with DVI video to up to four DVI monitors/projectors • Allows simultaneous display • Maintains video resolutions up to the highest DVI single link resolution of 1920 x 1200 • Supports DDWG standard for DVI monitors Includes: (1) 1:4 DVI Distribution Amplifi... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS... - Page 7 CONNECTING AND OPERATING THE 1:4 DISTRIBUTION AMPLIFIER How to Connect the 1:4 DVI Distribution Amplifi er Connect the supplied cable from the computer DVI source into the DVI input port of the 1:4 DVI Distribution Amplifi er. Connect the user supplied cable(s) from your display(s) into the DVI output port(s)* of the1:4 DVI Distribution Amplifi...
-
Page 8: Rack Ears Installation Diagram
RACK EARS INSTALLATION DIAGRAM Rack mount ears are provided for installation of this unit into a 1U rack mount space. Locate the side screws on the unit. Remove the front 2 screws that are located closest to the front of the unit. Using the removed screws, screw the rack mounting bracket into the unit. -
Page 9: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ..................165 MHz Input Video Signal ..................... 1.2 Volts p-p Input DDC Signal ..................5 Volts p-p (TTL) Single Link Range (Max. Resolution)..............1920 x 1200 Input Connector Type ..........DVI-I 29 pin female (DVI-D digital only) Output Connector Type ..........DVI-I 29 pin female (DVI-D digital only) Power Consumption .................. -
Page 10: Warranty
The information in this manual has been carefully checked and is believed to be accurate. However, Gefen assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will Gefen , be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. - Page 11 Rev X2 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com...
