1:4 HDMI Splitter
Accessories
Distribute One HDMI Source to Four Locations
The 1x4 HDMI splitter allows set-top boxes, DVD players, D-VHS players and other HDTV devices
with HDMI output to be connected to four or more HDTV displays.
How It Works
HDMI Cables
Gefen's 1x4 HDMI splitter is a distribution hub that sends the same video output to four or more
HDTV digital displays by itself and many more displays if multiple splitters are connected together.
Related Products
The HDMI splitter is connected using a HDMI cable from the HDMI source to the HDMI splitter
input. There are four HDMI outputs. HDMI Output #1 is the Primary output, where the
characteristics and capabilities of the Primary Display are retrieved and then used to drive all the
other displays.
Note: This HDMI product supports BOTH Audio and Video signals.
All displays that cannot show the same video resolution(s) as the Primary Display connected to
Output #1 may fail to show a picture. Secondary displays follow the Primary by sharing the
1:4 HDMI Splitter
resolution and capability information (EDID) obtained from the Primary Display.
Black
DVI, HDCP & HDMI Defined
Features:
Connects up to four HDMI™ / DVI displays at the same time to one video source
Allows simultaneous display
Maintains high resolution video - beautiful, sharp HDTV resolutions up to 1080p, 2k, and
computer resolutions up to 1920 x 1200 are easily achieved
HDMI™ compliant
HDCP compliant
Specifications:
Video Amplifier Bandwidth: 165 MHz
Input Video Signal: 1.2 volts p-p
Input DDC Signal: 5 volts p-p (TTL)
Single Link Range: 1080p/1920 x 1200
HDMI Connector: type A 19 pin female
Power Supply: 5V DC
Power Consumption: 10 watts (max)
Dimensions: 12"W x 1.25"H x 4.25"D
Shipping Weight: 5 lbs.
Package Includes:
1x4 HDMI splitter
One 5v Power Supply
One 6ft cable
User's Manual
Dystrybucja i sprzedaż: Meditronik Sp. z o.o.
02-952 Warszawa, ul. Wiertnicza 129, tel. (+48 22) 651-72-42, fax (+48 22) 651-72-46
http://www.meditronik.com.pl
e-mail: office@meditronik.com.pl
EXT-HDMI-144
Advertisement
Table of Contents
Related Manuals for Gefen EXT-HDMI-144
Summary of Contents for Gefen EXT-HDMI-144
-
Page 1: Specifications
How It Works HDMI Cables Gefen's 1x4 HDMI splitter is a distribution hub that sends the same video output to four or more HDTV digital displays by itself and many more displays if multiple splitters are connected together. Related Products The HDMI splitter is connected using a HDMI cable from the HDMI source to the HDMI splitter input. - Page 2 1:4 Distribution Amplifi er Model # EXT-HDMI-144 U S E R M A N U A L www.gefen.com...
- Page 3 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. is a trademark of Gefen Inc. 1:4 Distribution Amplifi er For HDMI HDMI™...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction / Operation Notes Features Panel Descriptions Connecting and Operating the 1:4 HDMI Distribution Amplifi er For HDMI Dip Switch Guidelines Specifi cations Warranty... -
Page 5: Introduction / Operation Notes
INTRODUCTION The Gefen 1:4 HDMI Distribution Amplifi er is the perfect solution for anyone who needs to send one source of digital high defi nition video to multiple displays at the same time. It supports all HDMI equipment, such as DVD players and satellite set top boxes and all HDMI displays. -
Page 6: Features
FEATURES Features • Connects up to four HDMI/DVI* displays at the same time to one video source • Allows simultaneous display • Supports resolutions up to 1080p, 2K, and 1920 x 1200 • Extends the range of HDMI compliant devices by equalizing and re-clocking the HDMI signal •... -
Page 7: Panel Descriptions
PANEL DESCRIPTIONS... - Page 8 CONNECTING AND OPERATING THE 1:4 DISTRIBUTION AMPLIFIER FOR HDMI How to Connect the 1:4 Distribution Amplifi er For HDMI Connect the supplied cable from the HDTV HDMI source into the HDMI input port of the 1:4 Distribution Amplifi er For HDMI. Connect the user supplied cable(s) from your display(s) into the HDMI output port(s) of the1:4 Distribution Amplifi...
-
Page 9: Dip Switch Guidelines
To access the Dip Switches, remove all screws from the bottom and sides of the Gefen unit. Carefully slide the unit apart. The 8 Bank of Dip Switches are located on the main PCB. Once adjustments are complete, slide the unit back together and replace all removed screws. -
Page 10: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ................165 MHz Input Video Signal ................... 1.2 Volts p-p Input DDC Signal ................5 Volts p-p (TTL) Single Link Range ..............1080p / 1920 x 1200 Input Connector Type ..............HDMI Type A 19 Pin Output Connector Type ..............HDMI Type A 19 Pin Power Consumption ................
