- Page 1 DVI DL Super Booster Plus EXT-DVI-141DLBP User’s Manual www.gefen.com...
- Page 2 DVI DL Super Booster Plus is a trademark of Gefen Inc. © 2009 Gefen Inc., All Rights Reserved All trademarks are the property of their...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Features Panel Layout Connecting And Operating The DVI DL Super Booster Plus Dip Switch Location Specifi cations Warranty... -
Page 4: Introduction
HDTV systems of all sizes with hard-working solutions that are easy to implement and simple to operate. The Gefen DVI DL Super Booster Plus The DVI DL Booster Plus uses a plug-in power supply which helps to extend sparkling clear video images to great distances (up to 200 feet at 2560x1600). -
Page 5: Features
FEATURES Features • Perfects video sent over long stretches of Dual- Link DVI cables • Extends DVI Dual Link displays away up to 200 feet • Supports resolutions up to 3840x2400 @ 60 Hz • Supports DDWG standards for DVI compliant monitors •... -
Page 6: Panel Layout
PANEL LAYOUTS Front Panel DVI In Back Panel Power LED DVI Out EQ Trim Pot... -
Page 7: Connecting And Operating The Dvi Dl Super Booster Plus
CONNECTING AND OPERATING THE DVI DL SUPER BOOSTER PLUS How to Connect the DVI DL Super Booster Plus Connect the long DVI cable from the source into the “DVI In” on the front of the DVI DL Super Booster Plus. The DVI DL Super Booster Plus is placed next to your display to regenerate the DVI signal. -
Page 8: Dip Switch Location
DIP SWITCH LOCATION Auto Auto Manual EQ Manual EQ Short Cable Long Cable Automatic Equalization Dip Switch 2 can be used to turn on the automatic equalization function. Use this setting for ease of setup as this mode will automatically tune out unwanted video noise. To do this, turn Dip Switch 2 to the ON position. -
Page 9: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ......2 x 165 MHz Input Video Signal ......... 1.2 Volts p-p Input DDC Signal ........5 volts p-p (TTL) Maximum Dual Link Range ....3840 x 2400 x 60hz DVI Input/Output Connector ....... DVI-D (29 pin) Power Consumption ........ -
Page 10: Warranty
Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi... - Page 11 Rev A4 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com...
