3 .0 Using your 90si

3 .1

Applying Power

The Easy-Fax 90si STU-III Gateway uses an external power supply. Since the 90si has no ON/OFF switch, the
device is "on" as soon as power is applied. To confirm that the 90si is properly powered and ready to operate,
ensure that the Green "POWER" light is illuminated and that the Red "FAULT" indicator is extinguished.
3 .2

Sending a Secure Fax

Use the following, generic, procedure to send a secure fax. You may want to make a version for your secure phone
and COTS fax that references the appropriate details.
Step
1.
2.
3.
4.
5.
6.
Off-Hook
Most fax machines have a button that when depressed, returns dial-tone from the telephone system. This button
is often labeled Hook, Manual Dial, Monitor, On Hook Dial or something to that effect. If your fax only has a
handset lift it off-hook, dial a "1" and press the Start button and then hang it back in its' cradle. If your fax does
not have a handset or a hook button (many HP faxes don't) simply eliminate this step (i.e. use 1, Start).
Secure/Non-Secure Differentiation
Secure faxes are always initiated from the secure phone / crypto and then the secure phone is placed in secure data
mode for the duration of the secure fax transmission. The 90si will not allow public faxes to be initiated from the
secure phone / crypto.
3 .3

Receiving a Secure Fax

Important: Your commercial fax device MUST be set to auto-receive as a fax for your 90si system to work
properly. Additionally, make sure that your fax is set to auto-answer on the fewest number of rings it will allow.
Ideally one or two rings. (See your faxes manual).
Step
1.
2.
3.
4.
3 .4

Sending a Public Fax (Dual-Mode Configurations Only)

www.gwfs.com, 877-951-9800, info@gwfs.com
Procedure
Place a call on your secure telephone / crypto.
Place it in secure data mode and set the handset on the table
Load your document in the facsimile
Take the fax machine "off-hook", dial a "1" and press the big Start or Sent button
(this will use the default transmit protocol)
The fax will begin sending pages, one at a time, and will indicate when it's done,
usually with a beep.
When the fax is done, you may return the call to Secure or Clear Voice or discon-
nect.
Procedure
Answer the incoming call on your secure telephone
Place it in secure data mode (either end may do this)
Standby, the fax will be received automatically
When the fax is done, you may return the call to Secure or Clear Voice or disconnect
help line: 877-951-9814
Model 90si Secure Fax Gateway User's Guide
page 20
