2 .3 .6 1-Line Dual-Mode with 910 Option

This configuration requires the optional Model 910 Auto Fax/STE Switch which allows your fax to function as
both your Primary non-secure as well as your Primary secure fax while using only one telephone line. No operator
need be present to receive a non-secure fax.
Set the Configuration to (03) 2-Line Dual-Mode. See Section 2.4, Setting Your Chosen Configuration, for in-
structions on how to do this.
90si Secure Fax Gateway
Rear Panel
5VDC Power
Supply
www.gwfs.com, 877-951-9800, info@gwfs.com
TEL LINE
"Red"
Data Port
Secure Telephone
/ Crypto
(Set to Async 9.6kbps)
Figure 4: 1-Line, Dual-Mode with 910 Option Configuration
Model 90si Secure Fax Gateway
LINE
FAX
Model 910
Automatic
Fax/STE
PSTN
help line: 877-951-9814
Commercial-Off-The-Shelf
Fax Machine
(Set to Auto-Answer on 1 Ring)
Phone
Line
Telephone
Switch
Wall Jack
User's Guide
page 11
