8.8 PREDEFINED MESSAGES

Used to send a predefined system message.
To send a Predefined Message, push [F] then push
[A] or [B] until the selection is displayed, then enter
the target radio ID, push [D] and enter a message
number and push [#]. The target radio should send
and ACK if successful.
Figure 18 shows Message 2 ready to be sent to
366.
Short Message
To: 366
Message :2
Figure 18

8.9 RADIO MONITOR

Used to key up a target radio from 10 to 60 sec-
onds and monitor the transmit audio.
To monitor a radio, push [F] then push [A] or [B]
until the selection is displayed, then enter the tar-
get radio ID, push [D] and enter 1 (10 seconds), 2
(30 seconds), or 3 (60 seconds).
Figure 19 shows Radio Monitor request to 366 to
transmit for 30 seconds.
Radio Monitor
To: 366
TX Mult :1
Figure 19

8.10 SBC LOG

To toggle the SBC Log ON, push [SHIFT] + [F],
to turn the log OFF, push [F]. When the SBC Log
is entered, the last SBC call is displayed. Push
[B] to scroll to the previous records and push [A]
to scroll to the end of the list. The radio will store
up to 99 log entries. When more than 99 entries
are made the oldest log will be deleted.
NOTE: When the radio is reset or reprogrammed,
all logs are deleted.
Figure 20 shows the fifth entry of the SBC Log.
Figure 20
5
MD N
MD N
<SBC Log>
5: To: 00000366 F
Radio Monitor
TX Mult: 3

9 P25 SQUELCH ADJUSTMENT

Push [SHIFT] + [MON] to choose the P25 squelch
mode.
Normal SQL = If NAC is the same, the receiver will
unmute
Selective SQL = If NAC and GROUP is the same, the
receiver will unmute
Figure 21 shows Normal SQ.
Figure 22 shows Selective SQ.
RX
TX
C001 TAC 2
Normal SQL
Figure 21
RX
TX
C001 TAC 2
Selective SQL
Figure 22

10 TALKGROUP ALIAS ID

When GPC is selected with the [A] key, the TGID alias
is indicated as programmed (Maximum 8 characters).
Figure 23 shows POLICE for the TGID alias.
RX
TX
C001 TAC 2
GPC POLICE
Figure 23
MD N
MD S
MD N
