Tools Necessary:
Phillips
head
OR
Adjustable
Wrench
BEFORE
YOU START:
Make sure the electrical power cord is unplugged from the wall outlet.
Remove any food from the door shelves.
Close the doors.
1
2
3
TO
1
2
TO
1
REMOVE THE HINGE COVER:
Remove the three screws from the cover over the top door hinges.
Pull the cover forward about a half inch and lift it off.
REMOVE THE REFRIGERATOR
DOOR:
Trace lightly around the door's top hinge with a pencil. This makes
reinstallation easier.
2 Remove the two screws from the top hinge. Lift the door off of the bottom
hinge and set it aside.
3 Remove the three bottom hinge screws and hinge, if necessary.
TO REMOVE THE FREEZER
DOOR:
1 Detach the multi-wire cable connector located above the top hinge. Grasp
both sides of the connector firmly and pull apart.
2 Trace lightly around the door's top hinge with a pencil. This makes
reinstallation easier.
3 Detach the water tube from the connector located below the freezer door.
The connector releases when you press its outer sleeve inward.
4 Remove the screws from the top hinge and pull the
multi-wire cable through it.
5 Lift the door off of the bottom hinge. Lay the door
on its side to avoid damage to the water tube
extending from the bottom hinge. Remove the
three bottom hinge screws and hinge, if necessary.
To reinstall the refrigerator and freezer doors, reverse
the above steps.
