Installation Guide
For Models:
RU72AG
RU72OBG
RU72SS
E192641
net weight of fan: 32.41 lb. (14.7 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 6
Warranty. pg. 9
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RU72AG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Craftmade RU72AG

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Models: RU72AG Table of Contents: RU72OBG Safety Tips. pg. 1 RU72SS Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.
  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (2.13m) (76cm) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. 12ft.
  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. If you wish to extend the hanging length of your fan, you must remove the hanging ball from the 6in. downrod provided to use with an extended downrod (sold separately). [If you wish to use the 6in. downrod, please proceed to instructions following the dotted line below.] To remove hanging ball, loosen set screw on hanging ball, lower hanging ball and remove stop...
  • Page 6 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you are safety cable loop wood now ready to hang your fan. Grab the fan ceiling firmly with two hands. Slide downrod through joist opening in hanging bracket and let hanging ball rest on the hanging bracket.
  • Page 7: Wiring

    6. Wiring. white supply wire CAUTION: Be sure outlet box is properly grounded ground or that a ground wire (GREEN or Bare) is present. (green or bare) black supply wire Make sure all electrical connections comply with from ceiling Local Codes or Ordinances and the National wire connector Electrical Code.
  • Page 8: Canopy Assembly

    7. Canopy Assembly. Locate 2 screws on underside of hanging bracket and remove screw closest to the open end of the hanging bracket. Partially loosen the other screw. Lift canopy to hanging bracket hanging bracket. Place rounded part of slotted hole in canopy over loosened screw in hanging bracket and push up.
  • Page 9: Switch Housing Assembly

    motor housing 9. Switch Housing Assembly. Remove 3 screws from outer edge of switch housing plate (save screws for later use). fitter Remove 1 screw from fitter plate on underside of motor plate switch housing male plug and partially loosen the other 2 screws. Align slotted plate holes in center of switch housing plate with loosened screws in fitter plate, allowing male plug from motor...
  • Page 10: Troubleshooting

    Return fan, shipping prepaid, to 2. Verify that reverse switch is set completely in Craftmade/Ellington. We will repair or ship you a either direction. replacement fan, and we will pay the return shipping cost.

This manual is also suitable for:

Ru72obgRu72ss
