1
Round-trip times
configured on the remote site ServerIron ADX, the passive RTT information is also gathered and sent
out to the GSLB controller. You can check the features on a ServerIron ADX using show feature
command on a BP console. If "SLB only" is display as "ON," that means that the ServerIron ADX will
only process basic load balance traffic.
FIGURE 9
1. Client sends a DNS query
for www.brocade.com to
LDNS. LDNS sends the query
to the GSLB ServerIron.
There are several advantages to the passive RTT gathering mechanism. Some of them are:
•
•
•
Although there are many advantages to using passive RTT gathering, this mechanism may not be
adequate in some situations.
•
•
Active RTT gathering
ServerIron ADX supports active RTT gathering where all Site ServerIron ADXs gather the RTT by
sending probes to the client's local DNS (LDNS) servers. They report this measured RTT to the
GSLB controller using the GSLB protocol. The GSLB controller uses this RTT to select the best IP
address for the client.
142
Passive RTT gathering
LDNS
Client
RTT measurements are done passively by the Site ServerIron ADX using the existing traffic
flow. No new traffic is introduced in the network to gather RTT.
Measurements always reflect the RTT between the client and the Site ServerIron ADX, not the
local DNS server (LDNS) of the client and the Site ServerIron ADX. This is an important
advantage if the client and its LDNS server are not topographically close to each other.
Since RTT is passively determined from the connection initiated by the client, the Site
ServerIron ADX will always be able to gather RTT.
If the client and its LDNS do not share the same network prefix, GSLB ServerIron ADX will not
be able to use the passively gathered RTT values for IP address selection.
Also, RTT can be gathered by a Site ServerIron ADX only if the client opens a connection to it.
The GSLB ServerIron ADX needs to distribute a percentage of resolution requests to ensure
that all the Site ServerIron ADXs have a chance to gather RTT.
2. The GSLB ServerIron
replies with the optimal IP
address for the client.
3. Site ServerIron uses
passive RTT gathering to
determine RTT.
ServerIron ADX Global Server Load Balancing Guide
GSLB ServerIron
4. Site ServerIron reports
RTT for client to GSLB
ServerIron using GSLB
protocol.
Site ServerIron
53-1002437-01
