Installing The Expansion Card

Insert the PCIe x4 card into the connector on the system board and press 1 .
. down to secure it in place
Insert the PCIe x16 card (if any) into the connector on the system board and 2 .
. press down to secure it in place
front bezel
. Install the 3 .
cover
. Install the 4 .
After Working Inside Your Computer
. Follow the procedures in 5 .
16
