Dell OptiPlex 390 Small Form Factor Owner's Manual page 87

one 24-pin and one 4-pin connector
Blue light — Solid blue light
indicates power-on state; blinking
blue light indicates sleep state of
Amber light — Solid amber light
when the computer does not start
indicates a problem with the
system board or power supply.
Blinking amber light indicates a
. problem with the system board
Blue light — Blinking blue light
indicates that the computer is
reading data from or writing data to
Four lights located on the front
panel of the computer. For more
information on the diagnostic lights,
see the Service Manual at
. support.dell.com/manuals
Green light — The power supply is
turned on and is functional. The
power cable must be connected to
the power connector (at the back
87
one 5-pin connector
one 3-pin connector
one 3-pin connector
one 5-pin connector
one 3-pin connector
. the computer
. the hard drive
System Board Connectors
Small Form Factor
Power button light
Drive activity light
Diagnostic lights
Power supply diagnostic light
Password clear jumper
RTC reset jumper
Internal speaker
Intruder connector
Power connector
Controls and Lights
: Front of the computer
: Back of the computer
