Owner's Manual

DVD Recorder

Supplied Accessory
• Remote control
• RF cable
(NA816UD)
with two AA batteries
If you need additional operating assistance after reading this owner's manual or to
Before you use this unit, you need to complete connections.
Refer to "Connections" on pages 13-15.
To record a program easily, refer to "Easy DVD recording" on pages 16-17
after connections are completed.
(You CANNOT record on any copyright protected DVD disc with this DVD recorder.)
INSTRUCCIONES EN ESPAÑOL INCLUIDAS
INSTRUCTIONS EN FRANÇAIS INCLUSES
• Audio/Video cables
(WPZ0901TM002 or
(WPZ0102TM015 or
WPZ0901CAB01)
WPZ0102LTE01)
Please read before using this equipment.
order replacement accessories, please call
TOLL FREE : 1-800-605-8453
or visit our web site at http://www.funai.us
FDR-90E
VCR Plus+ and PlusCode are registered trademarks of
Gemstar Development Corporation.The VCR Plus+
system is manufactured under license from Gemstar
Development Corporation.
• Owner's Manual
(1VMN20268)
Owner's Manual
• Quick Use Guide
(1VMN20269)
