Replacing The System Board - Dell Inspiron 17 Service Manual

1 captive screws (2) 2 PCH cooler
21. Remove the processor heat sink (see
22. Remove the processor module (see
Replacing the System Board
1. Follow the instructions in Before You
2. Replace the processor module (see
3. Replace the processor heat sink (see
4. Align the captive screws on the PCH cooler with the screw holes on the system board.
5. Tighten the two captive screws that secure the PCH cooler to the system board.
6. Turn the system board over.
7. Align the connectors on the system board with the slots on the computer base.
8. Use the alignment posts on the computer base to correctly place the system board.
9. Replace the eight screws that secure the system board to the computer base.
10. Connect the status light board cable to the connector on the system board.
11. Connect the display cable to the connector on the system board, and replace the display cable grounding screw.
12. Connect the speaker cable, subwoofer cable, and the AC adapter connector cable to the connectors on the system board.
13. Replace the processor fan (see
14. Replace the Bluetooth card (see
15. Replace the coin-cell battery (see
16. Replace the palm rest (see
17. Replace the keyboard (see
18. Follow the instructions from
19. Replace the Mini-Card (see
20. Replace the memory module(s) (see
21. Replace the module cover (see
Removing the Processor Heat
Removing the Processor Module).
Begin.
Replacing the Processor Module).
Replacing the Processor Heat
Replacing the Processor Fan).
Replacing the Bluetooth Card).
Replacing the Coin-Cell Battery).
Replacing the Palm Rest).
Replacing the Keyboard).
step 5 to step 7 in Replacing the Hard
Replacing the Mini-Card).
Replacing the Memory Module(s)).
Replacing the Module Cover).
Sink).
Sink).
Drive.
