SMC Networks TigerSwitch 100 SMC6924VF Management Manual

Stackable fast ethernet switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TigerSwitch 100
Stackable Fast Ethernet Switch
N 24 100BASE-FX VF-45 ports
N Optional 100BASE-FX or 1000BASE-X modules
N Optional stack module for linking up to four units
N 8.8 Gbps of aggregate switch bandwidth
N Support for redundant power unit
N Up to five port trunks per switch
N Port mirroring for non-intrusive analysis
N QoS support for two-level priority
N Full support for IEEE 802.1Q VLANs
N IGMP multicast filtering and snooping
N Manageable via console, Web, SNMP/RMON

Management Guide

SMC6924VF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TigerSwitch 100 SMC6924VF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks TigerSwitch 100 SMC6924VF

Summary of Contents for SMC Networks TigerSwitch 100 SMC6924VF

  • Page 1: Management Guide

    TigerSwitch 100 Stackable Fast Ethernet Switch N 24 100BASE-FX VF-45 ports N Optional 100BASE-FX or 1000BASE-X modules N Optional stack module for linking up to four units N 8.8 Gbps of aggregate switch bandwidth N Support for redundant power unit N Up to five port trunks per switch N Port mirroring for non-intrusive analysis N QoS support for two-level priority...
  • Page 3 TigerSwitch 100 Management Guide From SMC’s Tiger line of feature-rich workgroup LAN solutions 6 Hughes Irvine, CA 92618 June 2001 Phone: (949) 707-2400 Pub. # F2.47 150xxx-10x R01...
  • Page 4 Irvine, CA 92618 All rights reserved. Printed in Taiwan Trademarks: SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are trademarks of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.

  • Page 5: Limited Warranty

    IMITED ARRANTY Limited Warranty Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller.
  • Page 6 * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase. SMC Networks, Inc. 6 Hughes Irvine, CA 92618...

  • Page 7: Table Of Contents

    ABLE OF ONTENTS Switch Management ..... . 1-1 Configuration Options ......1-1 Required Connections .
  • Page 8 ABLE OF ONTENTS Displaying the Current STA for Ports ..2-39 Using a Mirror Port for Analysis ....2-41 Configuring Port Trunks .
  • Page 9 ABLE OF ONTENTS Agent Module ......3-10 Expansion Slot ......3-10 IP Configuration .
  • Page 10 ABLE OF ONTENTS Configuring IGMP ......3-41 IP Multicast Registration Table ....3-42 Port Menus .
  • Page 11 ABLE OF ONTENTS Console Port to 25-Pin DCE Port on Modem ..B-2 Console Port to 25-Pin DTE Port on PC ... . .B-3 Glossary Index...
  • Page 12 ABLE OF ONTENTS...

  • Page 13: Switch Management

    HAPTER WITCH ANAGEMENT Configuration Options For advanced management capability, the TigerSwitch 100 management agent provides a menu-driven system configuration program. This program can be accessed by a direct or modem connection to the serial port on the rear panel (out-of-band), or by a Telnet connection over the network (in-band).

  • Page 14: Required Connections

    WITCH ANAGEMENT Required Connections Console Port (Out-of-Band) Connections Attach a VT100 compatible terminal or a PC running a terminal emulation program to the serial port on the switch’s rear panel. Use the null-modem cable provided with this package, or use a null modem connection that complies with the wiring assignments shown in Appendix B of this guide.

  • Page 15: Remote Management Via The Console Port

    WITCH ANAGEMENT Remote Management via the Console Port Configure the Switch Site Connect the switch’s DB9 serial port to the modem’s serial port using standard cabling. For most modems which use a 25-pin port, you will have to provide an RS-232 cable with a 9-pin connector on one end and a 25-pin connector on the other end.

  • Page 16: In-Band Connections

    WITCH ANAGEMENT In-Band Connections Prior to accessing the Network Management Module via a network connection, you must first configure it with a valid IP address, subnet mask, and default gateway using an out-of-band connection or the BOOTP protocol. After configuring the switch’s IP parameters, you can access the on-board configuration program from anywhere within the attached network.
  • Page 17 MMMM CCCCCCCCCCCCCC TigerSwitch 100 SMC6924VF V2.47 05-30-2001 (c)Copyright 2000, SMC Networks Inc. User name : Password If this is your first time to log into the configuration program, then the default user names are “admin” and “guest,” with no password.

  • Page 18: Using The System Configuration Program

    SING THE YSTEM ONFIGURATION ROGRAM You should define a new administrator password, record it and put it in a safe place. Select Console Login Configuration from the Management Setup Menu and enter a new password for the administrator. Note that passwords can consist of up to 11 alphanumeric characters and are not case sensitive.

  • Page 19: Main Menu

    SING THE YSTEM ONFIGURATION ROGRAM Main Menu With the system configuration program you can define system parameters, manage and control the switch, the connected stack and all its ports, or monitor network conditions. The figure below of the Main Menu and the following table briefly describe the selections available from this program.
  • Page 20 SING THE YSTEM ONFIGURATION ROGRAM Menu Description Management Setup Menu Network Configuration Includes IP setup, Ping facility, HTTP (Web agent) setup, Telnet configuration, and MAC address. Serial Port Configuration Sets communication parameters for the serial port, including management mode, baud rate, console time-out, and screen data refresh interval.
  • Page 21 SING THE YSTEM ONFIGURATION ROGRAM Menu Description Extended Bridge Displays/configures extended bridge Configuration capabilities provided by this switch. 802.1P Configuration Configures default port priorities and queue assignments. 802.1Q VLAN Displays basic VLAN information, such as Base Information VLAN version number and maximum VLANs supported.

  • Page 22: System Information Menu

    SING THE YSTEM ONFIGURATION ROGRAM Menu Description Static Multicast Address Used to manually configure host MAC Table Configuration* addresses in the multicast table. Restart System Restarts system with options to use POST, or to retain factory defaults, IP settings, or user authentication settings.

  • Page 23: Displaying System Information

    System Information ================== System Description : TigerSwitch 100 SMC6924VF System Object ID : 1.3.6.1.4.1.202.20.6 System Up Time : 48067 (0 day, 1 hr, 2min, 34 sec)

  • Page 24: Displaying Switch Version Information

    SING THE YSTEM ONFIGURATION ROGRAM Displaying Switch Version Information Use the Switch Information screen to display hardware/firmware version numbers for the main board, as well as the power status. Switch Information : Unit 1 ================== Main Board Hardware Version : V5.0 Firmware Version : V1.21 Serial Number...
  • Page 25 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Agent Module Hardware Version Hardware version of the agent module. POST ROM Version Power-On Self-Test version number. Firmware Version Firmware version of the agent module. SNMP Agent Shows that the agent module is operating as Master.

  • Page 26: Management Setup Menu

    SING THE YSTEM ONFIGURATION ROGRAM Management Setup Menu After initially logging onto the system, adjust the communication parameters for your console to ensure a reliable connection (Serial Port Configuration). Specify the IP addresses for the switch (Network Configuration / IP Configuration), and then set the Administrator and User passwords (Console Login Configuration).

  • Page 27: Changing The Network Configuration

    SING THE YSTEM ONFIGURATION ROGRAM Menu Description Console Login Sets user names and passwords for system Configuration access, as well as the invalid password threshold and lockout time. TFTP Download Downloads new version of firmware to update your system (in-band). Configuration Save Saves the switch configuration to a file on a &...

  • Page 28: Ip Configuration

    SING THE YSTEM ONFIGURATION ROGRAM Parameter Description MAX Number of Allowed The maximum number of Telnet sessions Telnet Sessions allowed to simultaneously access the agent module. MAC Address Physical address of the agent module. IP Configuration Use the IP Configuration screen to set the bootup option, or configure the switch’s IP parameters.
  • Page 29 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Default Gateway Gateway used to pass trap messages from the system’s agent to the management station. Note that the gateway must be defined if the management station is located in a different IP segment. The default value is null. IP State Specifies whether IP functionality is enabled via manual configuration, or set by Boot Protocol (BOOTP).

  • Page 30: Ip Connectivity Test (Ping)

    SING THE YSTEM ONFIGURATION ROGRAM IP Connectivity Test (Ping) Use the IP Connectivity Test to see if another site on the Internet can be reached. The screen shown below is described in the following table. Network Configuration : IP Connectivity Test (Ping) =================================================== IP Address : Test Times : 1...

  • Page 31: Http Configuration

    SING THE YSTEM ONFIGURATION ROGRAM HTTP Configuration Use the HTTP Configuration screen to enable/disable the on-board Web agent, and to specify the TCP port that will provide HTTP service. The screen shown below is described in the following table. Network Configuration : HTTP Configuration ========================================== HTTP Server : ENABLED...

  • Page 32: Configuring The Serial Port

    SING THE YSTEM ONFIGURATION ROGRAM Configuring the Serial Port You can access the on-board configuration program by attaching a VT100 compatible device to the switch’s serial port. (For more information on connecting to this port, see “Required Connections” on page 1-2.) The communication parameters for this port can be accessed from the Serial Port Configuration screen shown below and described in the following table.
  • Page 33 SING THE YSTEM ONFIGURATION ROGRAM Parameter Default Description Parity None Sets the parity of the RS-232 port. Options : none/odd/even Time-Out 10 minutes If no input is received from the attached device after this interval, the current session is automatically closed. Range : 0 - 100 minutes;...

  • Page 34: Assigning Snmp Parameters

    SING THE YSTEM ONFIGURATION ROGRAM Assigning SNMP Parameters Use the SNMP Configuration screen to display and modify parameters for the Simple Network Management Protocol (SNMP). The switch includes an on-board SNMP agent which monitors the status of its hardware, as well as the traffic passing through its ports.

  • Page 35: Configuring Community Names

    SING THE YSTEM ONFIGURATION ROGRAM Configuring Community Names The following figure and table describe how to configure the community strings authorized for management access. Up to 5 community names may be entered. SNMP Configuration : SNMP Communities ===================================== Community Name Access Status public...

  • Page 36: Configuring Ip Trap Managers

    SING THE YSTEM ONFIGURATION ROGRAM Configuring IP Trap Managers The following figure and table describe how to specify management stations that will receive authentication failure messages or other trap messages from the switch. Up to 5 trap managers may be entered. SNMP Configuration : IP Trap Managers ===================================== IP Address...

  • Page 37: Console Login Configuration

    SING THE YSTEM ONFIGURATION ROGRAM Console Login Configuration Use the Management Setup: Console Login Configuration to restrict management access based on specified user names and passwords, or to set the invalid password threshold and time-out. There are only two user types defined, ADMIN (Administrator) and GUEST, but you can set up to five different user names and passwords.
  • Page 38 SING THE YSTEM ONFIGURATION ROGRAM Parameter Default Description Password Sets the password intrusion threshold Threshold which limits the number of failed logon attempts. Range : 0~65535 Lock-out Time 0 The time (in seconds) the management console will be disabled due to an excessive number of failed logon attempts.

  • Page 39: Downloading System Software

    SING THE YSTEM ONFIGURATION ROGRAM Downloading System Software Using TFTP to Download Over the Network Use the TFTP Download menu to load software updates into the switch. The download file should be an SMC6924VF binary file from SMC; otherwise the agent will not accept it. The success of the download operation depends on the accessibility of the TFTP server and the quality of the network connection.

  • Page 40: Saving The System Configuration

    SING THE YSTEM ONFIGURATION ROGRAM Saving the System Configuration Use the Configuration Save & Restore menu to save the switch configuration settings to a file on a TFTP server. The file can be later downloaded to the switch to restore the switch’s settings. The success of the operation depends on the accessibility of the TFTP server and the quality of the network connection.
  • Page 41 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Configuration Download Download Server IP IP address of a TFTP server. Download Filename The name of the file that contains the switch configuration settings you wish to restore. [Process TFTP Issues a request to the TFTP server to download Download] the specified file.

  • Page 42: Configuring The Switch

    SING THE YSTEM ONFIGURATION ROGRAM Configuring the Switch The Device Control menu is used to control a broad range of functions, including port configuration, Spanning Tree, port mirroring, multicast filtering, and Virtual LANs. Each of the setup screens provided by these configuration menus is described in the following sections.
  • Page 43 SING THE YSTEM ONFIGURATION ROGRAM Menu Description BStorm Control Allows you to enable/disable broadcast storm Configuration control on a per-port basis and set the packet-per-second threshold. Extended Bridge Displays/configures extended bridge capabilities Configuration provided by this switch. 802.1P Configuration Configures default port priorities and queue assignments.

  • Page 44: Configuring Port Parameters

    SING THE YSTEM ONFIGURATION ROGRAM Configuring Port Parameters Use the Port Configuration menus to set or display communication parameters for any port or module in the stack. Port Configuration : Unit 1 Port 1 - 12 ================== Flow Control on all ports : [Enable] [Disable] Port Type Admin...
  • Page 45 SING THE YSTEM ONFIGURATION ROGRAM Parameter Default Description Flow Control Disabled Used to enable or disable flow control. Flow control can eliminate frame loss by “blocking” traffic from end stations or segments connected directly to the switch when its buffers fill. IEEE 802.3x flow control is used for full duplex.

  • Page 46: Viewing The Current Port Configuration

    SING THE YSTEM ONFIGURATION ROGRAM Viewing the Current Port Configuration The Port Information screen displays the port type, status, link state, and flow control in use, as well as the communication speed and duplex mode. To change any of the port settings, use the Port Configuration menu.
  • Page 47 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description FlowControl InUse Shows the flow control type in use. Flow control can eliminate frame loss by “blocking” traffic from end stations connected directly to the switch. Back pressure is used for half duplex and IEEE 802.3x for full duplex.

  • Page 48: Using The Spanning Tree Algorithm

    SING THE YSTEM ONFIGURATION ROGRAM Using the Spanning Tree Algorithm The Spanning Tree Algorithm can be used to detect and disable network loops, and to provide backup links between switches, bridges or routers. This allows the switch to interact with other bridging devices (that is, an STA-compliant switch, bridge or router) in your network to ensure that only one route exists between any two stations on the network.
  • Page 49 SING THE YSTEM ONFIGURATION ROGRAM Parameter Default Description Spanning Tree Enabled Enable this parameter to participate in a STA Protocol compliant network. Priority 32,768 Device priority is used in selecting the root device, root port, and designated port. The device with the highest priority becomes the STA root device.
  • Page 50 SING THE YSTEM ONFIGURATION ROGRAM Parameter Default Description The maximum time (in seconds) a device can (Message) wait without receiving a configuration message before attempting to reconfigure. All device ports (except for designated ports) should receive configuration messages at regular intervals. Any port that ages out STA information (provided in the last configuration message) becomes the designated port for the attached LAN.

  • Page 51: Configuring Sta For Ports

    SING THE YSTEM ONFIGURATION ROGRAM Configuring STA for Ports The following figure and table describe port STA configuration. Spanning Tree Port Configuration : Unit 1 Port 1 - 12 ================================ Fast forwarding on all ports : [Enable] [Disable] Port Type Priority Cost FastForwarding...
  • Page 52 SING THE YSTEM ONFIGURATION ROGRAM Parameter Default Description (Path) Cost 100/19/4 This parameter is used by the STA algorithm to determine the best path between devices. Therefore, lower values should be assigned to ports attached to faster media, and higher values assigned to ports with slower media.

  • Page 53: Viewing The Current Spanning Tree Information

    SING THE YSTEM ONFIGURATION ROGRAM Viewing the Current Spanning Tree Information The Spanning Tree Information screen displays a summary of the STA information for the overall bridge or for a specific port. To make any changes to the parameters for the Spanning Tree, use the Spanning Tree Configuration menu.
  • Page 54 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Priority Device priority is used in selecting the root device, root port, and designated port. The device with the highest priority becomes the STA root device. However, if all devices have the same priority, the device with the lowest MAC address will then become the root device.

  • Page 55: Displaying The Current Sta For Ports

    SING THE YSTEM ONFIGURATION ROGRAM Displaying the Current STA for Ports The parameters shown in the following figure and table are for port STA Information. Spanning Tree Port Information : Unit 1 Port 1 - 12 ============================== Port Type Status Designated Designated Designated...
  • Page 56 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Status Displays current state of this port within the Spanning Tree: No Link No link has been established on this port. Disabled Port has been disabled by the user or has failed diagnostics. Blocking Port receives STA configuration messages, but does not forward packets.

  • Page 57: Using A Mirror Port For Analysis

    SING THE YSTEM ONFIGURATION ROGRAM Using a Mirror Port for Analysis You can mirror traffic from any source port to a target port for real-time analysis. You can then attach a logic analyzer or RMON probe to the target port and study the traffic crossing the source port in a completely unobtrusive manner.

  • Page 58: Configuring Port Trunks

    SING THE YSTEM ONFIGURATION ROGRAM Configuring Port Trunks Port trunks can be used to increase the bandwidth of a network connection or to ensure fault recovery. You can configure up five trunk connections (combining 2~4 ports into a fat pipe) between any two standalone SMC6924VF switches, or up to 12 for an entire stack.
  • Page 59 SING THE YSTEM ONFIGURATION ROGRAM You can use the Port Trunking Configuration screen set up port trunks as shown below: Port Trunking Configuration =========================== Trunk ID Status Member List --------- -------- ----------- ----------- ----------- ----------- -------- Unit : - Unit : - Unit : - Unit : - Port : --...
  • Page 60 SING THE YSTEM ONFIGURATION ROGRAM The VF-45 ports used for one side of a trunk must all be on the same internal switch chip. The port groups permitted include: Group 1 Group 2 Group 3 1,2,3,4, 5,6,7,8, 9,10,11,12, 13,14,15,16 17,18,19,20 21,22,23,24 The 100BASE-FX fiber ports used for one side of a trunk must all be on the same module.

  • Page 61: Igmp Multicast Filtering

    SING THE YSTEM ONFIGURATION ROGRAM IGMP Multicast Filtering Multicasting is used to support real-time applications such as video conferencing or streaming audio. A multicast server does not have to establish a separate connection with each client. It merely broadcasts its service to the network, and any hosts which want to receive the multicast register with their local multicast switch/ router.

  • Page 62: Configuring Igmp

    SING THE YSTEM ONFIGURATION ROGRAM Configuring IGMP This protocol allows a host to inform its local switch/router that it wants to receive transmissions addressed to a specific multicast group. You can use the IGMP Configuration screen to configure multicast filtering shown below. IGMP Configuration ================== IGMP Status...

  • Page 63: Configuring Broadcast Storm Control

    SING THE YSTEM ONFIGURATION ROGRAM Configuring Broadcast Storm Control Use the Broadcast Storm Control Configuration screen to enable broadcast storm control for any port on the switch, as shown below. Broadcast Storm Control Configuration : Unit 1 Port 1 - 12 ====================================== Broadcast control on all ports : [Enable]...

  • Page 64: Configuring Bridge Mib Extensions

    SING THE YSTEM ONFIGURATION ROGRAM Configuring Bridge MIB Extensions The Bridge MIB includes extensions for managed devices that support Traffic Classes and Virtual LANs. To display and configure these extensions, use the Extended Bridge Configuration screen as shown below. Extended Bridge Configuration ============================= Bridge Capability : (Read Only) Extended Multicast Filtering Services : NO...
  • Page 65 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Configurable This switch allows you to override the default PVID Tagging PVID (Port VLAN ID) assigned to untagged incoming frames under “802.1Q VLAN Port Configuration” on page 2-58.) Local VLAN Capable This switch does not support multiple local bridges (that is, multiple Spanning Trees).

  • Page 66: Configuring Traffic Classes

    SING THE YSTEM ONFIGURATION ROGRAM Configuring Traffic Classes IEEE 802.1p defines up to 8 separate traffic classes. This switch supports Quality of Service (QoS) by using two priority queues, with Weighted Fair Queuing for each port. You can use the 802.1P Configuration menu to configure the default priority for each port, or to display the mapping for the traffic classes as described in the following sections.

  • Page 67: Port Priority Configuration

    SING THE YSTEM ONFIGURATION ROGRAM Port Priority Configuration Inbound frames that do not have any VLAN tags are tagged with the input port’s default VLAN ID (PVID) and the Default Ingress User Priority as shown in the following menu, and then sorted into the appropriate priority queue at the output port.

  • Page 68: 802.1P Port Traffic Class Information

    SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Number of Egress Indicates that this switch supports two priority Traffic Classes output queues. 802.1p Port Traffic Class Information This switch provides two priority levels with Weighted Fair Queuing for port egress. This means that any frames with a priority tag from 0~3 are sent to the low priority queue “0”...

  • Page 69: Configuring Virtual Lans

    SING THE YSTEM ONFIGURATION ROGRAM Configuring Virtual LANs You can use the VLAN configuration menu to assign any port on the switch to any of up to 256 LAN groups. In conventional networks with routers, broadcast traffic is split up into separate domains.

  • Page 70: 802.1Q Vlan Current Table Information

    SING THE YSTEM ONFIGURATION ROGRAM Parameter Description MAX Supported VLANs Maximum number of VLANs that can be configured on this switch. Current Number of The number of VLANs currently configured on VLANs Configured this switch. 802.1Q VLAN Current Table Information This screen shows the current port members of each VLAN and whether or not the port supports VLAN tagging.
  • Page 71 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Creation Time The value of sysUpTime (System Up Time) when this VLAN was created. Status Shows how this VLAN was added to the switch. Dynamic GVRP: Automatically learned via GVRP. Permanent: Added as a static entry. Unit Stack unit.

  • Page 72: 802.1Q Vlan Static Table Configuration

    SING THE YSTEM ONFIGURATION ROGRAM 802.1Q VLAN Static Table Configuration Use this screen to create a new VLAN or modify the settings for an existing VLAN. You can add/delete port members for a VLAN from any unit in the stack as a tagged or untagged member. Or you can prevent a port from being automatically added to a VLAN by the GVRP protocol.
  • Page 73 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Forbidden Egress Ports Prevents a port from being automatically added to this VLAN via GVRP. Note that GVRP is not supported in the current firmware release. Untagged Ports You can add a port to the displayed VLAN as an untagged port by setting this field to “1”...

  • Page 74: 802.1Q Vlan Port Configuration

    SING THE YSTEM ONFIGURATION ROGRAM 802.1Q VLAN Port Configuration Use this screen to configure port-specific settings for IEEE 802.1Q VLAN features. 802.1Q VLAN Port Configuration : Unit 1 Port 1 - 12 =============================== Port PVID Acceptable Ingress GVRP GVRP Failed GVRP Last Frame Type Filtering...
  • Page 75 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description GVRP Status* Enables or disables GVRP for this port. When disabled, any GVRP packets received on this port will be discarded and no GVRP registrations will be propagated from other ports. Note that GVRP must be enabled for the switch before this setting can take effect.

  • Page 76: Port Security Configuration

    SING THE YSTEM ONFIGURATION ROGRAM Port Security Configuration Use the Port Security Configuration screen to enable and configure port security for the switch. Port Security allows you to configure each port with a list of MAC addresses of devices that are authorized to access the network through that port.
  • Page 77 SING THE YSTEM ONFIGURATION ROGRAM Parameter Description Mode Port security can be set to three states; Static, Disable, or Learning. When set to Static, the switch will drop packets from the port if the source MAC address does not match one of the addresses in the MAC Address list. If set to Learning, the switch will add the source MAC address of all packets received on the port to the authorized MAC Address list.

  • Page 78: Monitoring The Switch

    SING THE YSTEM ONFIGURATION ROGRAM Monitoring the Switch The Network Monitor Menu provides access to port statistics, RMON statistics, IP multicast addresses, and the static address table. Each of the screens provided by these menus is described in the following sections. Network Monitor Menu ==================== Port Statistics ...

  • Page 79: Displaying Port Statistics

    SING THE YSTEM ONFIGURATION ROGRAM Displaying Port Statistics Port Statistics display key statistics from the Ethernet-like MIB for each port. Error statistics on the traffic passing through each port are displayed. This information can be used to identify potential problems with the switch (such as a faulty port or unusually heavy loading).
  • Page 80 SING THE YSTEM ONFIGURATION ROGRAM Menu Description Multiple Collision A count of successfully transmitted frames for Frames* which transmission is inhibited by more than one collision. SQE Test Errors* A count of times that the SQE TEST ERROR message is generated by the PLS sublayer. Deferred A count of frames for which the first transmission Transmissions*...

  • Page 81: Displaying Rmon Statistics

    SING THE YSTEM ONFIGURATION ROGRAM Displaying RMON Statistics Use the RMON Statistics screen to display key statistics for each port from RMON group 1. (RMON groups 2, 3 and 9 can only be accessed using SNMP management software such as EliteView.) The following screen displays the overall statistics on traffic passing through each port.
  • Page 82 SING THE YSTEM ONFIGURATION ROGRAM Menu Description Multicast Frames The total number of good frames received that were directed to this multicast address. CRC/Alignment Errors The number of CRC/alignment errors (FCS or alignment errors). Undersize Frames The total number of frames received that were less than 64 octets long (excluding framing bits, but including FCS octets) and were otherwise well formed.

  • Page 83: Displaying The Unicast Address Table

    SING THE YSTEM ONFIGURATION ROGRAM Displaying the Unicast Address Table The Address Table contains the MAC addresses and VLAN identifier associated with each port (that is, the source port associated with the address and VLAN), sorted by MAC address or VLAN ID.
  • Page 84 SING THE YSTEM ONFIGURATION ROGRAM Menu Description The VLAN(s) associated with this address or port. Unit Switch unit in the stack (1~4). Port The port whose address table includes this MAC address. Status Indicates address status as: D: Dynamically learned, or P: Fixed permanently by SNMP network management software.

  • Page 85: Displaying The Ip Multicast Registration Table

    SING THE YSTEM ONFIGURATION ROGRAM Displaying the IP Multicast Registration Table Use the IP Multicast Registration Table to display all the multicast groups active on this switch, including multicast IP addresses and the corresponding VLAN ID. IP Multicast Registration Table =============================== Multicast IP Unit...

  • Page 86: Configuring Static Unicast Addresses

    SING THE YSTEM ONFIGURATION ROGRAM Configuring Static Unicast Addresses Use the Static Unicast Address Table Configuration screen to manually configure host MAC addresses in the unicast table. You can use this screen to associate a MAC address with a specific VLAN ID and switch port as shown below.
  • Page 87 SING THE YSTEM ONFIGURATION ROGRAM Menu Description Status The status for an entry can be set to: Permanent This entry is currently in use and will remain so after the next reset of the switch. DeleteOnReset This entry is currently in use and will remain so until the next reset.

  • Page 88: Resetting The System

    SING THE YSTEM ONFIGURATION ROGRAM Resetting the System Use the Restart command under the Main Menu to reset the management agent. The reset screen includes options as shown in the following figure and table. System Restart Menu =================== Restart Option : POST : YES Reload Factory Defaults...

  • Page 89: Web-Based Management

    HAPTER ASED ANAGEMENT Web-Based Configuration and Monitoring As well as the menu-driven system configuration program, the agent module provides an embedded HTTP Web agent. This agent can be accessed by any computer on the network using a standard Web browser (Internet Explorer 4.0 or above, or Netscape Navigator 4.0 or above).

  • Page 90: Navigating The Web Browser Interface

    ASED ANAGEMENT Navigating the Web Browser Interface To access the Web-browser interface you must first enter a user name and password. The default user name is “admin,” with no password. The administrator has Read/Write access to all configuration parameters and statistics. Home Page When your Web browser connects with the switch’s Web agent, the home page is displayed as shown below.

  • Page 91: Configuration Options

    ASED ANAGEMENT If this is your first time to access the management agent, you should define a new Administrator password, record it and put it in a safe place. From the Main Menu, select Security and enter a new password for the Administrator. Note that passwords can consist of up to 11 alphanumeric characters and are not case sensitive.

  • Page 92: Panel Display

    ASED ANAGEMENT Panel Display The Web agent displays an image of the switch’s ports, showing port links and activity. Clicking on the image of a port displays statistics and configuration information for the port. Clicking on the image of the serial port (labeled “Mgmt”) displays the Console Configuration screen.

  • Page 93: Console Configuration

    ASED ANAGEMENT Parameter Description Link Status Indicates if the port has a valid connection to an external device. Speed Status Indicates the current port speed. Duplex Status Indicates the port’s current duplex mode. Flow Control Status Shows the flow control type in use. Flow control can eliminate frame loss by “blocking”...
  • Page 94 ASED ANAGEMENT Parameter Default Description Time-Out 10 minutes If no input is received from the attached device after this interval, the current session is automatically closed. Range : 0 - 100 minutes; 0: disabled Data bits 8 bits Sets the data bits of the RS-232 port. Options : 7, 8 Stop bits 1 bit...

  • Page 95: Main Menu

    ASED ANAGEMENT Main Menu Using the on-board Web agent, you can define system parameters, manage and control the switch, the connected stack and all its ports, or monitor network conditions. The following table briefly describes the selections available from this program. Menu Description System...

  • Page 96: System Information

    ASED ANAGEMENT System Information Use the System Information screen to display descriptive information about the switch, or for quick system identification as shown in the following figure and table. Parameter Description Name assigned to the switch system. System Name* IP address of the agent you are managing. The agent IP Address supports SNMP over UDP/IP transport protocol.

  • Page 97: Switch Information

    ASED ANAGEMENT Switch Information Use the Switch Information screen to display hardware/firmware version numbers for the main board, as well as the power status and modules plugged into the system. Main Board Parameter Description Serial Number Serial number of the main board. Number of Ports Number of ports (including modules).

  • Page 98: Agent Module

    ASED ANAGEMENT Agent Module Parameter Description Hardware Version Hardware version of the agent module. POST ROM Version Agent module’s Power-On Self-Test version. Firmware Version Agent module’s firmware version. Role Shows that the agent module is operating as Master. Expansion Slot Parameter Description Expansion Slot 1...

  • Page 99: Ip Configuration

    ASED ANAGEMENT IP Configuration Use the IP Configuration screen to set the bootup option, configure the IP address for the on-board management agent, or set the number or concurrent Telnet sessions allowed. The screen shown below is described in the following table. Parameter Default Description...
  • Page 100 ASED ANAGEMENT Parameter Default Description IP Address 10.1.0.1 IP address of the switch you are managing. The switch supports SNMP over UDP/IP transport protocol. In this environment, all systems on the Internet, such as network interconnection devices and any PC accessing the on-board agent (or running EliteView) are assigned an IP address.

  • Page 101: Snmp Configuration

    ASED ANAGEMENT SNMP Configuration Use the SNMP Configuration screen to display and modify parameters for the Simple Network Management Protocol (SNMP). The stack should includes an SNMP agent module which monitors the status of its hardware, as well as the traffic passing through its ports.

  • Page 102: Trap Managers

    ASED ANAGEMENT Trap Managers The following figure and table describe how to specify management stations that will receive authentication failure messages or other trap messages from the switch. Up to 5 trap managers may be entered. Parameter Description Trap Manager Up to 5 trap managers may be used.

  • Page 103: Security Configuration

    ASED ANAGEMENT Security Configuration Use the Security Configuration screen to restrict management access based on a specified password. The Administrator has write access for parameters governing the SNMP agent. You should therefore assign a password to the Administrator as soon as possible, and store it in a safe place.

  • Page 104: Firmware Upgrade Options

    ASED ANAGEMENT Firmware Upgrade Options You can upgrade system firmware via a Web browser, a TFTP server, or a direct connection to the console port. Web Upload Management Use the Web Upload Management menu to load software updates into the switch. The upload file should be an SMC6924VF binary file from SMC;...

  • Page 105: Tftp Download Management

    ASED ANAGEMENT TFTP Download Management Use the TFTP Download Management menu to load software updates into the switch. The download file should be an SMC6924VF binary file from SMC; otherwise the agent will not accept it. The success of the download operation depends on the accessibility of the TFTP server and the quality of the network connection.

  • Page 106: Configuration Save And Restore

    ASED ANAGEMENT Configuration Save and Restore Use the Configure screen to save the switch configuration settings to a file on a TFTP server. The file can be later downloaded to the switch to restore the switch’s settings. The success of the operation depends on the accessibility of the TFTP server and the quality of the network connection.

  • Page 107: Configuration Download Management

    ASED ANAGEMENT Configuration Download Management Use the Configuration Download Management to restore switch configuration settings from a file on a TFTP sever. Parameters shown on this screen are indicated in the following figure and table. Parameter Description Server IP Address IP address of the TFTP server.

  • Page 108: Address Table Configuration

    ASED ANAGEMENT Address Table Configuration The Address Table contains the unicast MAC addresses and VLAN identifier associated with each port (that is, the source port), sorted by MAC address or VLAN. You can also clear the entire address table, or information associated with a specific address; or set the aging time for deleting inactive entries.

  • Page 109: Spanning Tree Algorithm (Sta)

    ASED ANAGEMENT Parameter Description New Static Use these fields to add or remove a static entry to the Address address table. Indicate the address, stack unit, port and VLAN group when adding a new entry. Add/Remove Adds/removes the selected address. Clear Table Removes all addresses from the address table.

  • Page 110: Spanning Tree

    ASED ANAGEMENT Spanning Tree The parameters shown in the following figure and table describe the current bridge STA Information. Parameter Description Spanning Tree State Shows if the switch is enabled to participate in an STA-compliant network. Bridge ID A unique identifier for this bridge, consisting of bridge priority plus MAC address (where the address is normally taken from the agent).

  • Page 111: Ports

    ASED ANAGEMENT Ports The parameters shown in the following figure and table are for port STA Information. Parameter Description Port Status Displays the current state of this port within the spanning tree: No Link No link has been established on this port. Disabled Port has been disabled by the user or has failed diagnostics.
  • Page 112 ASED ANAGEMENT Parameter Description The rules defining port status are: • A port on a network segment with no other STA compliant bridging device is always forwarding. • If two ports of a switch are connected to the same segment and there is no other STA device attached to this segment, the port with the smaller ID forwards packets and the other is blocked.

  • Page 113: Spanning Tree Configuration

    ASED ANAGEMENT Spanning Tree Configuration The following figures and tables describe Bridge STA configuration. Switch Parameter Default Description Usage Enabled Enable this parameter to participate in an STA compliant network. Priority 32,768 Device priority is used in selecting the root device, root port, and designated port.
  • Page 114 ASED ANAGEMENT Parameter Default Description The maximum time (in seconds) a device can (Message) wait without receiving a configuration message before attempting to reconfigure. All device ports (except for designated ports) should receive configuration messages at regular intervals. Any port that ages out STA information (provided in the last configuration message) becomes the designated port for the attached LAN.

  • Page 115: Sta Port Configuration

    ASED ANAGEMENT STA Port Configuration The following figure and table describe STA configuration for ports or modules. Parameter Default Description Fast Enabled See “Fast Forward” in this table. Forwarding Mode (All Ports) Priority Defines the priority for the use of a port in the STA algorithm.
  • Page 116 ASED ANAGEMENT Parameter Default Description Path Cost 100/19/4 This parameter is used by the STA algorithm to determine the best path between devices. Therefore, lower values should be assigned to ports attached to faster media, and higher values assigned to ports with slower media. The default and recommended range is: Standard Ethernet: 100 (50~600) Fast Ethernet:...

  • Page 117: Configuring Bridge Mib Extensions

    ASED ANAGEMENT Configuring Bridge MIB Extensions The Bridge MIB includes extensions for managed devices that support Traffic Classes and Virtual LANs. To display and configure these extensions, use the Bridge Extension screen as shown below: Bridge Capability Parameter Description Extended Multicast This switch does not support filtering of individual Filtering Services* multicast addresses based on GMRP (GARP Multicast...

  • Page 118: Bridge Settings

    ASED ANAGEMENT Bridge Settings Parameter Description Traffic Classes* Multiple traffic classes are supported by this switch as indicated under Bridge Capabilities. However, you can disable this function by setting this parameter to False. GARP Multicast Registration Protocol (GMRP) allows GMRP* network devices to register endstations with multicast groups.

  • Page 119: Priority

    ASED ANAGEMENT Priority IEEE 802.1p defines up to 8 separate traffic classes. This switch supports Quality of Service (QoS) by using two priority queues, with Weighted Fair Queuing for each port. You can use the Priority Menu to configure the default priority for each port, or to display the mapping for the traffic classes.

  • Page 120: Port Traffic Class Information

    ASED ANAGEMENT Parameter Description Port Numeric identifier for switch port. Default Ingress Default priority can be set to any value from 0~7, User Priority where 0~3 specifies the low priority queue and 4~7 specifies the high priority queue. Number of Egress Indicates that this switch supports two priority output Traffic Classes queues.

  • Page 121: Configuring Virtual Lans

    ASED ANAGEMENT Configuring Virtual LANs You can use the VLAN configuration menu to assign any port on the switch to any of up to 256 LAN groups. In conventional networks with routers, broadcast traffic is split up into separate domains. Switches do not inherently support broadcast domains. This can lead to broadcast storms in large networks that handle a lot of NetBeui or IPX traffic.

  • Page 122: Vlan Current Table

    ASED ANAGEMENT VLAN Current Table This screen shows the current port members of each VLAN and whether or not the port supports VLAN tagging. Ports assigned to a large VLAN group that crosses several switches should use VLAN tagging. However, if you just want to create a small port-based VLAN for one or two switches, you can assign ports to the same untagged VLAN.

  • Page 123: Vlan Static List

    ASED ANAGEMENT Parameter Description Egress Ports Shows the ports which have been added to the displayed VLAN group. Untagged Ports Shows the untagged VLAN port members. VLAN Static List Use this screen to create or remove VLAN groups. Parameter Description Current Lists all the current VLAN groups created for this system.

  • Page 124: Vlan Static Table

    ASED ANAGEMENT VLAN Static Table Use this screen to modify the settings for an existing VLAN. You can add/delete port members for a VLAN from any unit in the stack. (Note that VLAN1 is fixed as an untagged VLAN containing all ports in the stack, and cannot be modified via this screen.) Parameter Description...
  • Page 125 ASED ANAGEMENT Use the menu shown below to prevent a port from being dynamically added to the displayed VLAN group through GVRP. Parameter Description Forbidden Egress Prevents a port from being automatically added to this Ports VLAN via GVRP. Note that GVRP is not supported by the current firmware version.

  • Page 126: Vlan Static Membership By Port

    ASED ANAGEMENT VLAN Static Membership by Port Use the screen shown below to assign VLAN groups to the selected port. To perform detailed port configuration for a specific VLAN, use the VLAN Static Table (page 3-36). Parameter Description Port Number Port number on the switch selected from the upper display panel.

  • Page 127: Vlan Port Configuration

    ASED ANAGEMENT VLAN Port Configuration Use this screen to configure port-specific settings for IEEE 802.1Q VLAN features. Parameter Description PVID The VLAN ID assigned to untagged frames received on this port. Use the PVID to assign ports to the same untagged VLAN.

  • Page 128: Igmp Multicast Filtering

    ASED ANAGEMENT Parameter Description GVRP Last PDU The Source MAC Address of the last GVRP message Origin* received on this port. * GVRP is not available for the current firmware release. IGMP Multicast Filtering Multicasting is used to support real-time applications such as video conferencing or streaming audio.

  • Page 129: Configuring Igmp

    ASED ANAGEMENT Configuring IGMP This protocol allows a host to inform its local switch/router that it wants to receive transmissions addressed to a specific multicast address group. Use the IGMP Configuration screen to set key parameters for multicast filtering as shown below. Parameter Description IGMP Status...

  • Page 130: Ip Multicast Registration Table

    ASED ANAGEMENT IP Multicast Registration Table Use the IP Multicast Registration Table to display all the multicast groups active on this switch, including multicast IP addresses and the corresponding VLAN ID. Parameter Description VLAN ID VLAN ID assigned to this multicast group. Multicast IP address for specific multicast services.

  • Page 131: Port Menus

    ASED ANAGEMENT Port Menus Port Information The Port Information screen displays the port status, link state, the communication speed and duplex mode, as well as the flow control in use. To change any of the port settings, use the Port Configuration menu.

  • Page 132: Port Configuration

    ASED ANAGEMENT Port Configuration Use the Port Configuration menu to configure any port on the switch. Parameter Default Description Flow Control Disabled See “Flow Control Status” in this table. Mode (on all ports) Admin Status Enable Allows you to disable a port due to abnormal behavior, and then re-enable it after the problem has been resolved.
  • Page 133 ASED ANAGEMENT Parameter Default Description Flow Control Disabled Used to enable or disable flow control. Flow Status control can eliminate frame loss by “blocking” traffic from end stations or segments connected directly to the switch when its buffers fill. Back pressure is used for half duplex and IEEE 802.3x for full duplex.

  • Page 134: Port Broadcast Storm Protect Configuration

    ASED ANAGEMENT Port Broadcast Storm Protect Configuration Use the Port Broadcast Storm Protect Configuration screen to configure broadcast storm control for any port on the switch. Parameter Default Description Broadcast Storm Enabled Allows you to enable/disable broadcast Protect Mode storm control for all ports on the switch. Protect Status Enabled Enables/disables broadcast control for the...

  • Page 135: Port Security Configuration

    ASED ANAGEMENT Port Security Configuration Use the Port Security Configuration screen to enable and configure port security for the switch. Port Security allows you to configure each port with a list of MAC addresses of devices that are authorized to access the network through that port. Parameter Description Port Number...

  • Page 136: Using A Port Mirror For Analysis

    ASED ANAGEMENT Using a Port Mirror for Analysis You can mirror traffic from any source port to a target port for real-time analysis. You can then attach a logic analyzer or RMON probe to the target port and study the traffic crossing the source port in a completely unobtrusive manner.

  • Page 137: Port Trunk Configuration

    ASED ANAGEMENT Port Trunk Configuration Port trunks can be used to increase the bandwidth of a network connection or to ensure fault recovery. You can configure up five trunk connections (combining 2~4 ports into a fat pipe) between any two standalone SMC6924VF switches, or up to 12 for an entire stack.
  • Page 138 ASED ANAGEMENT Use the Port Trunking Configuration screen to set up port trunks as shown below: Parameter Description Trunk A unique identifier for this trunk. You can configure up to five trunks per switch. Status Enables or disables the displayed trunk. Member List You can create up to 12 trunks for the entire stack by specifying the trunk identifier, switch unit and port...
  • Page 139 ASED ANAGEMENT The VF-45 ports used for one side of a trunk must all be on the same internal switch chip. The port groups permitted include: Group 1 Group 2 Group 3 1,2,3,4, 5,6,7,8, 9,10,11,12, 13,14,15,16 17,18,19,20 21,22,23,24 The 100BASE-FX SC-type fiber ports used for one side of a trunk must all be on the same module.

  • Page 140: Port Statistics

    ASED ANAGEMENT Port Statistics Use the Port Statistics menu to display Etherlike or RMON statistics for any port on the switch. The statistics displayed are indicated in the following figure and table. Etherlike Statistics Etherlike Statistics display key statistics from the Ethernet-like MIB for each port.
  • Page 141 ASED ANAGEMENT Parameter Description Deferred A count of frames for which the first transmission Transmissions* attempt on a particular interface is delayed because the medium was busy. Late Collisions The number of times that a collision is detected later than 512 bit-times into the transmission of a packet. Excessive The number of frames for which transmission failed Collisions*...

  • Page 142: Rmon Statistics

    ASED ANAGEMENT RMON Statistics RMON Statistics display key statistics for each port or media module from RMON group 1. (RMON groups 2, 3 and 9 can only be accessed using SNMP management software such as EliteView.) The following screen displays overall statistics on traffic passing through each port.
  • Page 143 ASED ANAGEMENT Parameter Description Undersize Frames The total number of frames received that were less than 64 octets long (excluding framing bits, but including FCS octets) and were otherwise well formed. Oversize Frames The total number of frames received that were longer than 1518 octets (excluding framing bits, but including FCS octets) and were otherwise well formed.
  • Page 144 ASED ANAGEMENT Parameter Description 512-1023 Byte The total number of packets (including bad packets) Frames received and transmitted that were between 512 and 1023 octets in length inclusive (excluding framing bits but including FCS octets). 1024-1518 Byte The total number of packets (including bad packets) Frames received and transmitted that were between 1024 and 1518 octets in length inclusive (excluding framing bits...

  • Page 145: Advanced Topics

    HAPTER DVANCED OPICS This TigerSwitch 100 supports Layer 2 switching and other advanced features, which are described in this chapter. Layer 2 Switching When a frame enters a port, its destination MAC address is checked in the address database to see which port leads to this destination.

  • Page 146: Spanning Tree Algorithm

    DVANCED OPICS Spanning Tree Algorithm The Spanning Tree Algorithm (that is, the STA configuration algorithm as outlined in IEEE 802.1D) can be used to detect and disable network loops, and to provide link backup. This allows the switch to interact with other bridging devices (including STA-compliant switches, bridges or routers) in your network to ensure that only one route exists between any two stations on the network.

  • Page 147: Virtual Lans

    DVANCED OPICS The following figure gives an illustration of how the Spanning Tree Algorithm assigns bridging device ports. Virtual LANs Switches do not inherently support broadcast domains, which can lead to broadcast storms in large networks that handle a lot of IPX or NetBeui traffic.

  • Page 148: Assigning Ports To Vlans

    DVANCED OPICS VLANs provide greater network efficiency by reducing broadcast traffic, but also allow you to make network changes without having to update IP addresses or IP subnets. VLANs inherently provide a high level of network security, since traffic must pass through a Layer 3 switch or a router to reach a different VLAN.

  • Page 149: Port Overlapping

    DVANCED OPICS Port-based VLANs are tied to specific ports. The switch’s forwarding decision is based on the destination MAC address and its associated port. Therefore, to make valid forwarding and flooding decisions, the switch learns the relationship of the MAC address to its related port—and thus to the VLAN—at run-time.

  • Page 150: Connecting Vlan Groups

    DVANCED OPICS Connecting VLAN Groups The switch supports intra-VLAN communication using wire-speed switching. However, if you have devices in separate VLANs that must communicate, and it is not practical to include these devices in a common VLAN, then the VLANs can be connected via a Layer 3 switch (such as the SMC6724L3) or a router.

  • Page 151: Igmp Snooping

    DVANCED OPICS nodes join or leave multicast groups. A switch or router can then easily determine which ports contain group members and send data out to those ports only. This procedure is called multicast filtering. The purpose of multicast filtering is to optimize a switched network’s performance, so multicast packets will only be forwarded to those ports containing multicast group hosts or multicast routers/switches instead of flooding to all ports in the...

  • Page 152: Class-Of-Service (Cos) Support

    DVANCED OPICS Based on the group membership information learned from IGMP, a router/switch can determine which (if any) multicast traffic needs to be forwarded to each of its ports. At Layer 3, multicast routers use this information, along with a multicast routing protocol such as DVMRP, to support IP multicasting across the Internet.

  • Page 153: Port Trunks

    DVANCED OPICS Port Trunks Ports can be combined into an aggregate link to increase the bandwidth of a network connection or ensure fault recovery. You can group ports into trunks that consist of two, three or four ports, creating an aggregate bandwidth up to 8 Gbps when grouping multiple Gigabit ports.

  • Page 154: Remote Monitoring

    DVANCED OPICS event manager, log manager, MIB browser, RMON analysis tools, and device management modules. SMC also provides optional plug-in device management modules for HP OpenView. Remote Monitoring Remote Monitoring (RMON) provides a cost-effective way to monitor large networks by placing embedded or external probes on distributed network equipment (hubs, switches or routers).
  • Page 155 DVANCED OPICS storms, or other unusual events. Historical information can also be used to predict network growth and plan for expansion before your network becomes too overloaded. Alarms: Can be set to test data over any specified time interval, and can monitor absolute or changing values (such as a statistical counter reaching a specific value, or a statistic changing by a certain amount over the set interval).
  • Page 156 DVANCED OPICS 4-12...

  • Page 157: Troubleshooting

    PPENDIX ROUBLESHOOTING Troubleshooting Chart Troubleshooting Chart Symptom Action Cannot connect • Be sure to have configured the agent with a valid IP using Telnet, Web address, subnet mask and default gateway. browser, or SNMP • Check that you have a valid network connection to software the switch and that the port you are using has not been disabled.

  • Page 158: Upgrading Firmware Via The Serial Port

    2. When the system initialization screen appears as shown below, press “D” to download system firmware, and then indicate the code type (1: Runtime, 2: POST, 3: Mainboard). (c)Copyright 2001, SMC Networks Inc. SMC-6924VF Stackable Switch LOADER Version V1.02 POST Version V1.10...
  • Page 159 ROUBLESHOOTING 3. Change your baud rate to 115200 bps, and press Enter to enable download mode. From the terminal emulation program, select the file you want to download, set the protocol to XModem, and then initialize downloading. Notes: 1. If you use Windows HyperTerminal, disconnect reconnect to enable the new baud rate.
  • Page 160 ROUBLESHOOTING...

  • Page 161: Pin Assignments

    PPENDIX SSIGNMENTS Console Port Pin Assignments The DB-9 serial port on the switch’s rear panel is used to connect to the switch for out-of-band console configuration. The on-board menu-driven configuration program can be accessed from a terminal, a PC running a terminal emulation program, or from a remote location via a modem connection.

  • Page 162: Db-9 Port Pin Assignments

    SSIGNMENTS DB-9 Port Pin Assignments CCITT Description Switch’s PC DB9 Modem Signal Circuit Signal DB9 DTE DB25 Direction Pin # Pin # DCE Pin # DTE-DCE DCD (Data Carrier Detected) 1 <------ RxD (Received Data) <------ TxD (Transmitted Data) ------> 108.2 DTR (Data Terminal Ready) ------>...
  • Page 163 SSIGNMENTS Console Port to 25-Pin DTE Port on PC Switch’s 9-Pin Null Modem PC’s 25-Pin Serial Port DTE Port 1 DCD 8 DCD 2 RXD 3 TXD 3 TXD 2 RXD 4 DTR 20 DTR 5 SGND 7 SGND 6 DSR 6 DSR 7 RTS 4 RTS...
  • Page 164 SSIGNMENTS...
  • Page 165 LOSSARY Bandwidth Utilization The percentage of packets received over time as compared to overall bandwidth. BOOTP Boot protocol used to load the operating system for devices connected to the network. GARP VLAN Registration Protocol (GVRP) Defines a way for switches to exchange VLAN information in order to register necessary VLAN members on ports along the Spanning Tree so that VLANs defined in each switch can work automatically over a Spanning Tree network.
  • Page 166 IEEE 802.1D Specifies a general method for the operation of MAC bridges, including the Spanning Tree Protocol. IEEE 802.1Q VLAN Tagging defines Ethernet frame tags which carry VLAN information. It allows switches to assign end-stations to different virtual LANs, and defines a standard way for VLANs to communicate across switched networks.
  • Page 167 Port Trunk Defines network link aggregation and trunking standards which specify how to create a single high-speed logical link that combines several lower-speed physical links. Remote Monitoring (RMON) RMON provides comprehensive network monitoring capabilities. It eliminates the polling required in standard SNMP, and can set alarms on a variety of traffic conditions, including specific errors types.
  • Page 168 Trivial File Transfer Protocol (TFTP) A TCP/IP protocol commonly used for software downloads. Virtual LAN (VLAN) A Virtual LAN is a collection of network nodes that share the same collision domain regardless of their physical location or connection point in the network. A VLAN serves as a logical workgroup with no physical barriers, allowing users to share information and resources as though located on the same LAN.
  • Page 169 NDEX Numerics system restart menu 2-72 console port 802.1p port priority 3-31 configuration 2-16 802.1Q VLANs 2-53 3-33 connections 1-2 802.3x flow control 2-29 3-45 pin assignments B-1 analyzer port configuration 2-41 3-48 downloading software 2-23 3-16 duplex mode configuration 2-29 3-44 baud rate configuration 2-16 BOOTP...
  • Page 170 NDEX snooping 4-7 broadcast storm control 2-47 3-46 in-band connections 1-4 configuration 2-28 3-44 Internet Group Management Protocol information 2-30 3-43 overlapping 4-5 See IGMP IP configuration 2-12 3-11 priority 2-50 3-31 security 2-60 3-47 STA Information 2-39 3-23 trunks 4-9 configuration 3-49 Layer 2 switching 4-1 problems, troubleshooting A-1...
  • Page 171 NDEX STA 4-2 base information 2-53 3-33 configuration 2-32 3-21 3-25 current table information 2-54 statistics 3-34 port 2-63 3-52 port configuration 2-58 3-39 RMON 2-65 3-54 static table configuration 2-56 switch configuration 2-26 3-35 switching, Layer 2 4-1 connecting 4-6 system information 2-6 port overlapping 4-5 tagged 4-5...
  • Page 172 NDEX Index-4...
  • Page 174 FOR TECHNICAL SUPPORT, CALL: From U.S.A. and Canada (24 hours, 7 days a week) (800) SMC-4-YOU; (949) 707-2400; (949) 707-2460 (Fax) From Europe (8:00 AM - 5:30 PM UK Greenwich Mean Time) 44 (0) 1189 748740; 44 (0) 1189 748741 (Fax) INTERNET E-mail addresses: techsupport@smc.com...

Table of Contents
