SMC7824M/VSW
TigerAccess™ Extended Ethernet Switch
OVERVIEW
SMC's VDSL2 Extended Ethernet network solution provides an alternative cost-effective solution for net-
work/Internet access to multi-unit buildings or enterprise environments such as hospitals, universities, and
manufacturing facilities. Using existing category 1, 2, or 3 wiring, SMC's Extended Ethernet technology is
able to deliver up to 100Mbps of broadband connection for distances up to 800ft. SMC's Extended Ethernet
solution minimizes the hassle involved in rewiring by delivering both voice and data access on the same line
as Plain Old Telephone Service (POTs). SMC's EE solution is the best choice for service providers to supply
broadband access with minimal changes to existing wiring infrastructure.
VDSL2 enables the provider to offer a larger range services over the existing telephone wires which have
been unavailable due to the high bandwidth requirements such as HDTV streaming and Video On Demand.
KEY FEATURES
Increased Port Density
Supporting up to 24 ports of VDSL2 connectivity and 2 Gigabit Cop-
per ports for uplinks offers higher port density to deliver next gen-
eration services in a variety of hospitality environments.
Support for Advanced Applications
Software features including QoS and IGMP which are designed to
provide better support for Video On Demand and other enhanced
services for Hospitality Environments.
APPLICATION DIAGRAM
LEGEND
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
LEGEND
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
PHONE CABLES
WIRELESS
Bandwidth
Supporting up to a maximum of 100M Upstream and 100M Downstream
bandwidth. The bandwidth does change with increased distance but
still provides a high throughput for internet and advanced applications.
Support for Standard Features
As part of SMCs commitment to standards based networking so-
lutions the SMC7824M/VSW supports industry standard features.
This includes Spanning Tree, VLANs and 802.1x delivering reliable,
fl exible and secure solutions for hospitality environments.
