Using The Fastcheck™ Monitoring Utility; Installing Fastcheck - Gigabyte Promise RAID Function User Manual

5.
Using The FastCheck™ Monitoring Utility
You can monitor the operating status of all arrays and drives configured on the
RAID Function using the supplied FastCheck monitoring utility for Windows-based
operating systems. FastCheck generates visual and audible messages alerting you of
possible problems with the disk array or controller.
FastCheck visually identifies the physical location of attached drives on the
RAID Function IDE channel (1 or 2) and setting (Master/Slave/Cable-Select). It also
displays which drives are included as part of individual arrays. Administrators can
customize FastCheck to maintain operating logs and event notification, set Password
access to the utility, and schedule maintenance on Mirrored (RAID 1) or a Striped/
Mirrored (RAID 0/1) arrays.

5-1 Installing FastCheck

1. From the Start Button on the Windows Taskbar, choose Run.
2. Insert FastCheck Utility Diskette.
3. In the Run dialog box, type in "A:\" and click OK.
4. Follow the directions from the setup program.
5. During installation, click YES when prompted to run the utility on every startup. If
NO is selected, FastCheck will not initialize during startup. You may manually
execute the utility via the Start button.
NOTE: We recommends to have FastCheck load during Startup. This insures you
that it will be ready to post alerts on errors..
Using The FastCheck Monitoring Utility
