RAID Function
Installing Driver with Existing Windows NT 4.0
WARNING: If you plan to move your boot drive to a mirrored RAID 1
RAID Function array, hard drives should NOT be connected to the RAID Function
controller before performing the following procedure. The RAID Function drivers
must be loaded on the system hard drive (running under the existing hard drive
controller) before any hard drives are connected to the RAID Function controller.
1.
Choose "Settings" from the "Start" menu.
2.
Choose "Control Panel" from the "Settings" menu.
3.
Double-click on the "SCSI Adapters" icon, which generates the "SCSI Adapters"
dialog box.
4.
Choose "Drivers," and then press "Add."
5.
In the "Install Drivers" dialog box, press "Have Disk..."
6.
When the "Install From Disk" appears, insert the "RAID Function Driver"
diskette in drive A:.
7.
Type "A:\NT4" in the text box window, then choose "OK."
8.
When the "Install Driver" dialog box appears, select "Win NT Promise
MBFastTrak133 Lite Controller" and then press "OK."
9.
When the "Select SCSI Adapter Option" dialog box appears, press "Install."
10.
After a successful installation, the "SCSI Adapter Setup" box will show that the
"WinNT Promise MBFastTrak133 Lite Controller" has been installed.
11.
Power off your system.
12.
If moving the boot drive to the RAID Function , now attach the hard drives
otherwise reboot.
Removing the Driver from Windows NT 4.x
1.
In "Start" Button choose "Control Panel" in "Setup" group.
2.
In "Control Panel," select "SCSI Adapter," next choose "Drivers" label
3.
Choose "Remove" button.
4.
After successful removing, the "SCSI Adapter Setup" box will show that "Win NT
MBFastTrak133 Lite RAID Controller" has been removed.
2 8
