Create the findDoctor and findPatient Interactions

Create the findDoctor and findPatient Interactions
You use a database adapter to create the interactions used to get the data that you
need. The interactions are used as services when you set up the endpoint in
JDeveloper. For more information on using JDeveloper to create an endpoint, see
Process Manager
Do the following to create the interactions.

Add a Database Adapter

■

Create Interactions

■
Add a Database Adapter
You now create a database adapter, which lets you create interactions to get the
information you are seeking. To create a database adapter, do the following
Expand the computer you just added and then expand the NAV binding.
1.
Right-click the Adapters folder and then select New adapter.
2.
Enter the following information for your adapter, then click Finish.
3.
■
■
■
For a detailed explanation on how to set up a database adapter, see
Oracle Connect
The following figure shows the Add adapter dialog box with the correct information:
Figure 6–3 Add Adapter Dialog Box
Create Interactions
You create interactions to work with the data under the Oracle Application Server. You
use the interactions that you create when you create your endpoint using JDeveloper.
In this example, you should create an interaction called findDoctor. To create an
intearction, do the following:
6-4 Oracle Application Server Adapters for IMS/DB User's Guide
Examples.
Name: findDoctor
Type: Database
Select Create event queue for the adapter.
Adapter.
BPEL
Setting Up an
