Setting Up The Ibm Z/Os Platform In Oracle Studio - Oracle Application Server 10.1.3.4 User Manual

Configuring Oracle Connect
Securing Access to Oracle Connect
■
Modeling Interactions for OracleAS Adapter for IMS/DB
■

Setting Up the IBM z/OS Platform in Oracle Studio

Using Oracle Studio, perform the following steps to configure the IBM z/OS platform:
From the Start menu, select Programs, Oracle, and then select Studio. Oracle
1.
Studio opens, displaying the Design perspective.
Right-click Machines in the Configuration Explorer and select Add Machine. The
2.
Add Machine screen is displayed (see
Enter the name of the computer you want to connect to, or click Browse to select
3.
the computer from the list of computers that is displayed and which use the
default port (2551).
Specify the username and password of the user who was specified as the
4.
administrator when Oracle Connect was installed.
The Add Machine screen is shown in the following figure:
Figure 2–1 The Add Machine screen
Click Finish.
5.
2-14 Oracle Application Server Adapters for IMS/DB User's Guide
The following tasks assume you have permission to access
Note:
the IBM z/OS platform and that the Oracle Connect daemon is
running on this computer.
Check with the system administrator to ensure these requirements
are fulfilled.
Selecting Anonymous connection enables anyone having
Note:
access to the computer to be an administrator, if this was defined
for the computer.
Figure 2–1).
