Import The Metadata - Oracle Application Server 10.1.3.4 User Manual

In the Type field, select IMS-DLI and then click Finish. You do not need to add
4.
any additional connection information.
For detailed information on adding the IMS/DB data source, see
Source
The following figure shows the Add data source dialog box with the correct
information:
Figure 6–2 Add Data Source Dialog Box

Import the Metadata

You now import the metadata from the IMS/DB data into the data source. For
information on how to import data, see
Source.
In this example you should import the metadata for the Doctor and Patient
coluumns of the Hospital database. This database is supplied as an example with
Oracle Connect and should be installed when you install Oracle Connect on your
Mainframe computer.
You will need the following information for the metadata import:
In the Get Input Files step, add the files, hospital.dbd, hospital.cob, and
■
hospital.psb.
In the Apply Filters step, just click Next.
■
In the Select Tables step, select DOCTOR and PATIENT.
■
In the Match DBD to COBOL screen, click Next.
■
In the Import Manipulation step, click Next.
■
In the Metadata Model Selection step, select Default value for all tables, then click
■
Next.
In the Import Metadata step, select Yes and then click Finish.
■
Driver.
Configuring an OracleAS Adapter for IMS/DB for Outbound Interactions 6-3
Adding the IMS/DB Hospital Data Source
Importing Metadata for the IMS/DB Data
Configuring the Data
