Gigaset 1054 Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Gigaset Manuals
  4. Cordless Telephone
  5. Gigaset 1054
  6. Operating instructions manual

Gigaset 1054 Operating Instructions Manual

Cordless digital dect telephone system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Gigaset 1054: A30852-X954-B101-1-7619
28.10.96
1054TIT.FM
s
Gigaset 1054
Cordless Digital DECT Telephone System
8 mobile units
can be connected

Operating Instructions

2 non-cordless terminals
can be connected
Note:
Please read these instructions, with their safety
precautions, before using this equipment!
