Summary of Contents for Barco BARCOSLM R6

  • Page 1 ARCO ROJECTION SLM R6 ARCO R9001901 WNERS ANUAL 17092002 R5976483/01...
  • Page 2 Barco nv Events Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.88.24 E-mail: events@barco.com Visit us at the web: www.barco.com Printed in Belgium...
  • Page 3 Changes Barco provides this manual “as is” without warranty of any kind, either expressed or implied, including but not limited to the implied war- ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
  • Page 5: Table Of Contents

    7.2.3 Start up ......................... . 51 R5976483 BARCOSLM R6 17092002...
  • Page 6 9.7.3 Setting up the Interface Standard....................95 R5976483 BARCOSLM R6 17092002...
  • Page 7 B. Barco Control Manager ............... ..
  • Page 8 Table of contents R5976483 BARCOSLM R6 17092002...
  • Page 9: Safety Instructions

    Definition Qualified service technicians or Qualified technicians : Persons having appropriate technical training and experience nec- essary to be aware of hazards to which they are exposed in performing a task and of measures to minimize the danger to themselves or other persons. R5976483 BARCOSLM R6 17092002...
  • Page 10 1. Safety Instructions Extra Safety manual Read also safety instructions in separate manual (R5976125). R5976483 BARCOSLM R6 17092002...
  • Page 11: Packaging And Dimensions

    Lens Packaging • Projector Case 2.1 Box Content Content • 1 projector BARCO SLM R6 (weight ± 56 kg or 123.5 lbs) • 1 remote control unit RCU + 1 battery. • 1 European and 1 American power cable. •...
  • Page 12: Projector Case

    2. Packaging and Dimensions 2.4 Projector Case Dimensions The dimensions are given in mm 25.4mm = 1 inch Image 2-2 Front view dimensions Image 2-3 Side view dimensions R5976483 BARCOSLM R6 17092002...
  • Page 13 2. Packaging and Dimensions Image 2-4 Top view dimensions R5976483 BARCOSLM R6 17092002...
  • Page 14 2. Packaging and Dimensions R5976483 BARCOSLM R6 17092002...
  • Page 15: Installation Guidelines

    Special care should be used when DLP projectors are used in the same room as performant laser equipment. Direct or indirect hitting of a laser beam on to the lens can severely damage the Digital Mirror Devices (TM) in which case there is a loss of warranty R5976483 BARCOSLM R6 17092002...
  • Page 16: Configuration

    Which configuration can be used? The projector can be installed to project images in four different configurations: • Front/table • Rear/table • Front/ceiling • Rear/ceiling Positioning the projector Table mounted, front projection Image 3-1 Table mounted configuration R5976483 BARCOSLM R6 17092002...
  • Page 17 3. Installation Guidelines Table mounted, front projection, second way. Image 3-2 Table mounted configuration up side down Ceiling mounted, front projection Image 3-3 Ceiling mounted projector R5976483 BARCOSLM R6 17092002...
  • Page 18: Safety Area Around Projector

    Make sure the projector is located so that the air inlets and outlets for the cooling system are not obstructed. Leave a safety area A of about 1 meter on the left and the right side of the projector. R5976483 BARCOSLM R6 17092002...
  • Page 19: Re-Adjusting The Lamp Position In The Lamp Casing

    MORE... Number of strikes : Z_AXIS : 100 Select with Select with then <ENTER> then <ENTER> Select with <EXIT> to return <EXIT> to return then <ENTER> <EXIT> to return. Menu 3-1 Menu 3-2 Menu 3-3 R5976483 BARCOSLM R6 17092002...
  • Page 20: Lenses

    3. Installation Guidelines Image 3-6 Lamp adjustment access Image 3-7 Never turn the other screws ! These are factory aligned. 3.5 Lenses Overview • Lenses • Lens selection • Lens formulas • Lens Installation • Cleaning the lens R5976483 BARCOSLM R6 17092002...
  • Page 21: Lenses

    (B), until the lens clicks in the lens anchor system. (image 3-9) On a table mounted projector, hold the projector when pushing the lens into the lens block to avoid sliding off from Caution: the table. R5976483 BARCOSLM R6 17092002...
  • Page 22: Cleaning The Lens

    Other lenses can also be cleaned safely with this Toraysee cloth. 3.6 Battery Installation in the RCU How is the battery delivered ? A battery (not yet installed to save the battery life time) is delivered inside the plastic bag with the power cord. R5976483 BARCOSLM R6 17092002...
  • Page 23: Stacking Projectors

    5. Guide hook and cable around the carry handle and guide it around the carry handle of the upper projector. (image 3-15) 6. Hook it in the foreseen hole B in the base plate of the upper projector. (image 3-16) R5976483 BARCOSLM R6 17092002...
  • Page 24 3. Installation Guidelines Image 3-12 Stacking two projectors Image 3-13 Closing the rigging sockets Image 3-14 Image 3-15 Mounting the security chain Mounting the security hook R5976483 BARCOSLM R6 17092002...
  • Page 25 1. Push the ring (A) of the first projector downwards and hold it in that position. (image 3-17) 2. Turn the locked part (B) of the second projector a quarter counter clockwise and move it upwards. Image 3-17 Opening the rigging sockets R5976483 BARCOSLM R6 17092002...
  • Page 26: Rigging Points And Accessories

    2. Slide the clamps holders (2 per profile) on its place in the U-profile according the measured distance and secure this position. (image 3-20) 3. Turn the overlockers in the holes of the clamp holder. The overlocker can turn around. Image 3-20 Mounting the clamp — detail R5976483 BARCOSLM R6 17092002...
  • Page 27 2. Hook the clamp around the tube. The trigger automatically shuts the clamp. 3. Close the fixation handle and secure it by turning the hand screw. (image 3-22) Image 3-21 Opening the rigging clamp Image 3-22 Closing the rigging clamp R5976483 BARCOSLM R6 17092002...
  • Page 28 3. Installation Guidelines R5976483 BARCOSLM R6 17092002...
  • Page 29: Connections

    1. Press Stand by key once on the local keypad or on the remote control. The projector mode indication lamp will be green (image 4-1) Press a digit button to select an input source. Image 4-1 Standby indication R5976483 BARCOSLM R6 17092002...
  • Page 30: Switching To Standby

    The total lifetime of the lamp for a safe operation is 1000 or 1500 (depending on lamp type) hours max. Do not use it longer. Always replace with a same type of lamp. Call a BARCO authorized service technician for lamp replacement.
  • Page 31: Switching Off

    HD SDI Digital input (R9840450) Digital Video Decoder (R9841170) 4.5.2 Inputs via RCVDS05 Overview When using a RCVDS05, the input configuration must be as follows: slot 1 RGB/Component slot 2 Video slot 3 not used slot 4 not used R5976483 BARCOSLM R6 17092002...
  • Page 32: Input Module Insertion

    Slot 1 & 2 has 5 BNC input terminals for 5 cable input and a DVI plug for DVI input. Slot 1 has also an DVI output for loop through to a second projector. Within the installation mode it is possible to setup the input for 5 cable or DVI (panellink). R5976483 BARCOSLM R6 17092002...
  • Page 33 1. Press ADJUST or ENTER key to start up the Adjustment mode. to select Installation. (menu 4-3) 2. Push the cursor key 3. Press ENTER. to select Input Slots. (menu 4-4) 4. Press the cursor key R5976483 BARCOSLM R6 17092002...
  • Page 34: Serial Digital Input (Slot 3 & 4)

    1. Connect the output of your SDI source to the input BNC of the SDI input. (image 4-5) Note: The input is always 75 Ω terminated. 2. If loop through is needed, use the OUT to connect to the next device. R5976483 BARCOSLM R6 17092002...
  • Page 35: Hd Sdi Digital Input (Slot 3 & 4)

    1. Connect the output of your HD SDI source to the input BNC of the HD SDI input. (image 4-6) Note: The input is always 75 Ω terminated. 2. If loop through is needed, use the OUT to connect to the next device. R5976483 BARCOSLM R6 17092002...
  • Page 36: Digital Video Decoder Input

    Which signal can be connected to the Digital Video Decoder module? Connector name/ Y/Vid S-Video Input signal Component Video Composite Video Video S-Video S-Video How to connect? 1. Connect the output of your source to the corresponding inputs on the Digital Video Decoder module. (image 4-7) R5976483 BARCOSLM R6 17092002...
  • Page 37: Communication Connections

    <ENTER> then <ENTER> then <ENTER> <EXIT> to return <EXIT> to return <EXIT> to return Menu 4-6 Menu 4-7 Menu 4-8 4.6 Communication Connections Overview • RS232 (RS422) Connection • Communication with peripherals • Network connection R5976483 BARCOSLM R6 17092002...
  • Page 38: Rs232 (Rs422) Connection

    Once the webside is accessed, it is possible to check and manipulate all the projector settings. Remote diagnostics, control and monitoring of the projector can then become a daily and very simple operation. The network connectivity permits to detect potential errors and consequently improve the time to servicing. R5976483 BARCOSLM R6 17092002...
  • Page 39 4. Connections Image 4-8 Always use an ethernet cable with ferrite core to connect the projector to the LAN. R5976483 BARCOSLM R6 17092002...
  • Page 40 4. Connections R5976483 BARCOSLM R6 17092002...
  • Page 41: Getting Started

    "pause" (blanked picture, full power for immediate restarting) • direct access to all connected sources. 5.2 Terminology overview Overview The following table gives an overview of the different functionalities of the keys. Image 5-1 Local keypad & RCU R5976483 BARCOSLM R6 17092002...
  • Page 42: Operating The Projector

    Starting image projection. 1. Press Stand by key once on the local keypad or on the remote control. The projector mode indication lamp will be green (image 5-2) Press a digit button to select an input source. R5976483 BARCOSLM R6 17092002...
  • Page 43: Switching To Standby

    Automatic shutdown is activated.’. A ’-t’ appears on the LED display to indicate the user that the projector is switched to standby due to DMD temperature problems. Operating temperature range of the DMD : +10 C and +40 C. R5976483 BARCOSLM R6 17092002...
  • Page 44: Quick Set Up Adjustments

    Menu 5-3 Menu 5-4 5.4.2 Quick Lens Adjustment Quick zoom/focus adjustment 1. Press the Selection key *, Barco key. The zoom/focus menu will be displayed. (image 5-3) 2. Push the cursor key to zoom and to focus the image. 3. When finished, press EXIT key to return or ENTER to continue to the shift adjustment.
  • Page 45: Quick On Screen Color Change

    5. Getting Started Image 5-3 Quick shift adjustment 1. Press the Selection key *, Barco key. The zoom/focus menu will be displayed (image 5-3). 2. Press ENTER. The shift menu will be displayed. (image 5-4) 3. Push the cursor key to shift the image up or down and to shift the image left or right.
  • Page 46: Using The Rcu

    1. Plug one end of the remote cable in the connector on the bottom of the RCU. 2. Plug the other end in the connector in the front panel of the projector labelled RC. (image 5-6) Image 5-6 R5976483 BARCOSLM R6 17092002...
  • Page 47 When using the wireless remote control, make sure you are within the effective operating distance (30m, 100ft in a straight line). The remote control unit will not function properly if strong light strikes the sensor window or if there are obstacles between the remote control unit and the projector IR sensor. R5976483 BARCOSLM R6 17092002...
  • Page 48: Projector Address

    IBM PC (or compatible), Apple MAC, etc. for addresses between 0 and 255. Common Address Every projector has a common address ’0’ or ’1’. The choice between ’0’ and ’1’ can be selected in the Service mode. R5976483 BARCOSLM R6 17092002...
  • Page 49: Displaying And Programming Addresses

    The sound is not interrupted. The display on front of the projector will show a "P". To restart the image : • Press Pause key. • Press EXIT key • Select a source number. R5976483 BARCOSLM R6 17092002...
  • Page 50 5. Getting Started The Stand-by Key When the Stand-by key is pressed, the image projection is stopped and the projector goes to stand-by. This situation is used when a projection stop is planned for a longer period. R5976483 BARCOSLM R6 17092002...
  • Page 51: Start Up Of The Adjustment Mode

    Some items in the Adjustment mode are password protected. While selecting such an item, the projector asks to enter your password (Password protection is only available when the password strap on the controller module is ON, call an authorized service center to change the position of the password strap). R5976483 BARCOSLM R6 17092002...
  • Page 52: Menus On Local Lcd Display

    The menus will be displayed line by line in the same order as they were displayed on the projection screen. Adjustments can be done while the projector is running without projecting the disturbing menus on the screen. Use the cursor keys to scroll through the menus and press ENTER to activate the displayed menu. R5976483 BARCOSLM R6 17092002...
  • Page 53: Random Access Adjustment Mode

    7. Random Access Adjustment Mode 7. RANDOM ACCESS ADJUSTMENT MODE Overview • Overview Flow • Picture Services • Picture Tuning • Geometry • ScenergiX • Picture in Picture (PiP) 7.1 Overview Flow Overview Image 7-1 R5976483 BARCOSLM R6 17092002...
  • Page 54: Picture Services

    (see File Options, page 58). Files with a ~ in front of the file name are temporary files. These files will be deleted when switching to another source. R5976483 BARCOSLM R6 17092002...
  • Page 55: Start Up

    [Fit] : only the best fitting files will be displayed (with a distinction of ± 2 lines and line duration of ± 300 ns, if nothing is found within this small area, the projector continues searching until it finds something). R5976483 BARCOSLM R6 17092002...
  • Page 56: Edit File

    806 LINES ACTIVE 768 LINES START 36 LINES INTERLACED [OFF] READ AMDS OPTIONS Select with Select with then <ENTER> <ENTER> to accept <EXIT> to return <EXIT> to return <ENTER>, <EXIT> Menu 7-9 Menu 7-10 Menu 7-11 R5976483 BARCOSLM R6 17092002...
  • Page 57: Changing The Settings

    If not, adjust until full image height is displayed (no missing lines) Vertical Start number of lines between the start of the input signal and start of the image on the screen. R5976483 BARCOSLM R6 17092002...
  • Page 58 The choice exists to project [both] fields on the screen or only the [even] or [odd] field. This can be useful for 3D projection. Use the ENTER key to toggle between [both], [even] and [odd]. R5976483 BARCOSLM R6 17092002...
  • Page 59 Undesirable elements or defects in a video picture. These may occur naturally in the video process and must be eliminated in order to achieve a high-quality picture. Most common in analog are cross color and cross luminance. Most common in digital are macroblocks, which resemble pixelation of the video image. R5976483 BARCOSLM R6 17092002...
  • Page 60: Rename

    2. Press EXIT to return to the Rename menu selection. No changes are made. RENAME FILE From file name : Video525.c01 To file name : demo.c10 Select with Reprogram with or numeric keys <ENTER> to confirm <EXIT> to return Menu 7-16 R5976483 BARCOSLM R6 17092002...
  • Page 61: Copy

    To delete a selected file out of the list of files : to highlight Delete. (menu 7-20) 1. Push the cursor key 2. Press ENTER. The delete selection menu will be displayed. (menu 7-21) 3. Push the cursor key to select a file name. R5976483 BARCOSLM R6 17092002...
  • Page 62: File Options

    [automatic] : correct file will be loaded automatically. [manual] : correct file has to be loaded manually. 7.3 Picture Tuning Overview • Start up • Color Temperature • Gamma • Decoding • Dynamic Color Depth • Noise Reduction • Input Balance R5976483 BARCOSLM R6 17092002...
  • Page 63: Start Up

    If no, go to step 2 2. Push the cursor key to adjust red and push the cursor key to adjust blue (range 0 to 2.5)in comparison with the green color. (image 7-3) R5976483 BARCOSLM R6 17092002...
  • Page 64: Gamma

    PICTURE TUNING COLOR TEMPERATURE GAMMA DECODING [EBU] DYNAMIC COLOR DEPTH NOISE REDUCTION INPUT BALANCE Select with then <ENTER> <EXIT> to return Menu 7-30 7.3.5 Dynamic Color Depth Purpose Increases color contrast for all video and data sources. R5976483 BARCOSLM R6 17092002...
  • Page 65: Noise Reduction

    This procedure is not so easy. Overview • Input Balance for RGB input signals • Input Balance for YUV signals There are 2 different adjustment procedures, one for RGB (included Video and S-Video) and one for YUV input signals. R5976483 BARCOSLM R6 17092002...
  • Page 66: Input Balance For Rgb Input Signals

    5. Adjust with the cursor keys until the red respectively blue noise becomes visible in the white areas and return one step. INPUT BALANCE WHITE BALANCE BLACK BALANCE Select with then <ENTER> <EXIT> to return Menu 7-35 R5976483 BARCOSLM R6 17092002...
  • Page 67: Input Balance For Yuv Signals

    Using the cursor key to adjust Entering the value with the digit keys. Therefore, press ENTER to select the indicated value and enter the desired value with the digit keys. Press ENTER to confirm the entered value. R5976483 BARCOSLM R6 17092002...
  • Page 68: Geometry Start Up

    Menu 7-39 7.4.3 Shift What can be done ? The image can be shifted in a horizontal or vertical direction. Image 7-4 Shift adjustment Shift to the left Shift to the right Shift upwards Shift downwards R5976483 BARCOSLM R6 17092002...
  • Page 69: Size

    When adjusting the horizontal size, the left side of the image is fixed and only the right side can be moved to its exact position. Image 7-5 Size adjustment Horizontal size adjustment Vertical size adjustment R5976483 BARCOSLM R6 17092002...
  • Page 70: Side Keystone

    Blanking adjustments affect only the edges of the projected image and are used to frame the projected image on to the screen and to hide or black out unwanted information (or noise). A ’0’ on the bar scale indicates no blanking. R5976483 BARCOSLM R6 17092002...
  • Page 71: Aspect Ratio

    <ENTER> then <ENTER> <EXIT> to return <EXIT> to return Menu 7-43 Menu 7-44 7.4.7 Aspect Ratio Purpose To force the projector in a typical aspect ratio. E.g. projecting a 4:3 image in a 16:9 aspect ratio. R5976483 BARCOSLM R6 17092002...
  • Page 72: Scenergix

    Why ScenergiX ? When working in a multichannel setup the BARCO SLM R6 and its Soft Edge possibilities enable an image blending that gives the appearance of a single view, thus achieving realistic immersion for the majority of wide screen applications.
  • Page 73: Preparations

    ScenergiX Basic Principle 7.5.3 Preparations ScenergiX Preparations To ensure proper ScenergiX adjustment, be sure that the following adjustments are done perfectly on all projectors: • Convergence (Electronic Convergence). • Geometry • Color Matching (Color Temperature, Input Balance, Gamma) R5976483 BARCOSLM R6 17092002...
  • Page 74: Scenergix

    1. Go to File –> Edit menu of first projector. 2. Enter value for horizontal active (= Pact) as follow : Pact = [(Horz. resolution of 1 projector)/(Total horz. screen resolution)] x (horz. resolution source) 3. Horizontal start (= Pstart) remains the same. R5976483 BARCOSLM R6 17092002...
  • Page 75: Scenergix Overlap Zone (Vertical Scenergix)

    Lact = [(Vert.. resolution of 1 projector)/(Total vert.. screen resolution)] x (vert. resolution source) 3. Vertical start (= Lstart) = original start + [(Vert. resolution source) minus (newly calculated Lact)] Example Vertical resolution source : 1200 lines R5976483 BARCOSLM R6 17092002...
  • Page 76: Scenergix Size Adjustment

    Set first the width of the first projector and repeat for the second one. (image 7-13, image 7-14) SCENERGIX STATUS [ON] - size - BOTTOM LEFT RIGHT - black level - LEVEL Select with then <ENTER> <EXIT> to return Menu 7-48 R5976483 BARCOSLM R6 17092002...
  • Page 77 7. Random Access Adjustment Mode Image 7-12 Width selections Image 7-13 Width set up for projector 1 R5976483 BARCOSLM R6 17092002...
  • Page 78: Adjusting The Black Level Of The Images

    3. Adjust the black level of area A until the black level of area A, B and C are equal. (image 7-15) SCENERGIX STATUS [ON] - size - BOTTOM LEFT RIGHT - black level - LEVEL Select with then <ENTER> <EXIT> to return Menu 7-49 Image 7-15 Black level adjustment R5976483 BARCOSLM R6 17092002...
  • Page 79: Picture In Picture (Pip)

    The input section of the SLM projector allows a combinations of different input signals which may be projected in the 2 windows of the PiP screen. The PiP window can be placed in one of the four corners of the main window. Image 7-16 Possible position for PiP R5976483 BARCOSLM R6 17092002...
  • Page 80: Picture In Picture Activation

    Select with then <ENTER> <EXIT> to return Menu 7-52 7.6.4 Position of Picture in Picture window What can be done? The PiP window can be placed in on of the four corners of the main window. R5976483 BARCOSLM R6 17092002...
  • Page 81: Set Up Of The Quick Selection

    OFF : no quick selection allowed. <0> : quick selection allowed by using 0 before the source number. STATUS [ON] SOURCE 01 POSITION [Top-Left] QUICK SELECT [OFF] Select with then <ENTER> <EXIT> to return Menu 7-54 R5976483 BARCOSLM R6 17092002...
  • Page 82 7. Random Access Adjustment Mode R5976483 BARCOSLM R6 17092002...
  • Page 83: Installation Mode

    RGB-SS [CV] NO SIGNAL RGB-SOG CONVERGENCE CONFIGURATION LENS ______________ QUICK ACCESS KEYS 1. DVI OUTPUT [DVI input] INTERNAL PATTERNS Select with Select with then <ENTER> then <ENTER> <EXIT> to return <EXIT> to return Menu 8-3 Menu 8-4 R5976483 BARCOSLM R6 17092002...
  • Page 84: Peripheral

    Which module are available? When a RCVDS05 is connected to the projector, the type of output module of this RCVDS05 has to be defined in the 800 peripheral menu. • standard output module • 5 cable output module R5976483 BARCOSLM R6 17092002...
  • Page 85: Defining The Infrared Communication Protocol

    Switching from one source to another. To minimize undesired effects when switching from one source to another one can use the Seamless switching mode, beside Seam- less switching there is a choice between several effects which render the transitions more enjoyable. R5976483 BARCOSLM R6 17092002...
  • Page 86: No Signal

    When an effect is selected within seamless source switching, wait until the effect is terminated before switch- ing to another source (± 2 seconds). 8.5 No Signal Overview • Changing the Background Color • Changing the Shutdown Setting • Changing the Shutdown Time R5976483 BARCOSLM R6 17092002...
  • Page 87: Changing The Background Color

    Select with Select with then <ENTER> then <ENTER> <EXIT> to return <EXIT> to return Menu 8-13 Menu 8-14 8.5.3 Changing the Shutdown Time Range The shutdown time can be set between 5 min. and 60 min. R5976483 BARCOSLM R6 17092002...
  • Page 88: Convergence

    Menu 8-18 8.7 Configuration What can be done? The way of physical installation of the projector can be defined to the projector. The following installation configurations are possible: • front/table • front/ceiling • rear/table • rear/table R5976483 BARCOSLM R6 17092002...
  • Page 89: Lens Adjustment

    INPUT SLOTS ZOOM/FOCUS 800 PERIPHERAL SHIFT SOURCE SWITCHING OPTIONS NO SIGNAL CONVERGENCE CONFIGURATION LENS QUICK ACCESS KEYS INTERNAL PATTERNS Select with Select with then <ENTER> then <ENTER> <EXIT> to return <EXIT> to return Menu 8-20 Menu 8-21 R5976483 BARCOSLM R6 17092002...
  • Page 90: How To Zoom/Focus

    LENS ADJUSTMENT LENS OPTIONS ZOOM/FOCUS Use the same SHIFT zoom and focus OPTIONS of the lens for all files? [No] Select with then <ENTER> <ENTER> to toggle <EXIT> to return <EXIT> to return. Menu 8-24 Menu 8-25 R5976483 BARCOSLM R6 17092002...
  • Page 91: Quick Access Keys

    INPUT SLOTS 800 PERIPHERAL SOURCE SWITCHING MENU POSITION [Default] NO SIGNAL CONVERGENCE CONFIGURATION LENS QUICK ACCESS KEYS INTERNAL PATTERNS Select with Select with then <ENTER> then <ENTER> <EXIT> to return <EXIT> to return Menu 8-28 Menu 8-29 R5976483 BARCOSLM R6 17092002...
  • Page 92: 2Menu Position

    NO SIGNAL MULTIBURST CONVERGENCE CHECKER BOARD CONFIGURATION PURITY LENS PAGE CHAR QUICK ACCESS KEYS ALPHA_NUMERIC CHARS INTERNAL PATTERNS Select with Select with then <ENTER> then <ENTER> <EXIT> to return <EXIT> to return. Menu 8-32 Menu 8-33 R5976483 BARCOSLM R6 17092002...
  • Page 93: Service Mode

    9.3 Identification What can be seen on the identification screen? The identification screen shows the general information of the projector. The following items will be displayed: • Type of projector: BARCO SLM R6 • Software version • Network module: yes •...
  • Page 94: Password

    This item is password protected when the password strap is installed. The password function is enabled when the password strap, second switch of S2 on the controller module is installed. Consult an authorized Barco service technician to change the strap position. About password types.
  • Page 95: Access Control List

    <EXIT> to return <EXIT> to return Menu 9-6 Menu 9-7 9.4.2 Access Control List What is possible? In the access control list the owner can set up the access possibilities for the user and the guest. R5976483 BARCOSLM R6 17092002...
  • Page 96: Access Levels

    An access level can be added to the following items: • Adjustment mode • Barco logo • Change projector address • File delete • File delete all • Input balance • Installation • Random access • Serial communication • Service R5976483 BARCOSLM R6 17092002...
  • Page 97: Changing Language

    <ENTER> to confirm <EXIT> to return <EXIT> to return. Menu 9-13 Menu 9-14 9.7 Serial Communication Overview • Start Up of the Serial Communication • Baud rate Setting • Setting up the Interface Standard • RS422 Termination R5976483 BARCOSLM R6 17092002...
  • Page 98: Start Up Of The Serial Communication

    2. Press ENTER to toggle between the available baudrates. Default : 9600 SERIAL COMMUNICATION PROJECTOR ADDRESS 001 BAUDRATE [115200] INTERFACE STANDARD [RS232] RS422 TERMINATION [ON] Select with then <ENTER> <EXIT> to return Menu 9-17 Available baud rates. 115200/57600/38400/19200/9600/4800/1200 R5976483 BARCOSLM R6 17092002...
  • Page 99: Setting Up The Interface Standard

    Menu 9-19 9.8 Network Configuration DHCP Dynamic host configuration protocol What can be done? The necessary network addresses (configuration) can be entered so that the projector can be connected to a LAN (local area net- work). R5976483 BARCOSLM R6 17092002...
  • Page 100: Lamp

    The constant light output of projectors in a chain (maximum 12 projectors) can be set to the same value by linking the projectors via the RS232 connector. To the RS232in of the first projector, a terminator must be connected (Z3498823). The out of the first must be connected to the in of the next projector, etc. R5976483 BARCOSLM R6 17092002...
  • Page 101 [SLAVE] follows the master projector to adjust the CLO. When stand alone and the light output should be adjusted, put on slave. [MAS- master projector to control the CLO in a chain of projectors. TER] R5976483 BARCOSLM R6 17092002...
  • Page 102: Barco Logo

    OFF: no key on the RCU is used to display the BARCO logo. TEXT: the TEXT key on the RCU is used to display or to remove the BARCO logo with one single push on this key (only in operational mode).
  • Page 103: Preset Input Balance

    PRESET INPUT BALANCE ADVANCED PROCESSING is reserved to DIAGNOSIS qualified MORE... service personnel Select with then <ENTER> <ENTER> to accept <EXIT> to return <EXIT> to return Menu 9-31 Menu 9-32 9.13 Advanced Processing Overview • Minimum Delay R5976483 BARCOSLM R6 17092002...
  • Page 104: 1Minimum Delay

    The diagnosis menu will be displayed. (menu 9-36) SERVICE DIAGNOSIS BARCO LOGO ADD INS FORMATTER PRESET INPUT BALANCE SMPS ADVANCED PROCESSING DIAGNOSIS MORE... Select with Select with then <ENTER> then <ENTER> <EXIT> to return <EXIT> to return Menu 9-35 Menu 9-36 R5976483 BARCOSLM R6 17092002...
  • Page 105: C Diagnoses

    The SMPS overview menu will be displayed. (menu 9-42) DIAGNOSIS SMPS I2C (30H) FORMATTER AMBIENT SMPS TILT SWITCH MICRO SWITCH LAMP TEMP LPS MAINS POWER Select with then <ENTER> <EXIT> to return <EXIT> to return Menu 9-41 Menu 9-42 R5976483 BARCOSLM R6 17092002...
  • Page 106 9. Service Mode R5976483 BARCOSLM R6 17092002...
  • Page 107: Programmable Function Keys

    A confirmation menu will be displayed : " <F1> will be used to quickly access this menu". (menu 10-1) CONFIRM QUICK ACCESS <F1> will be used to quickly access this menu. <ENTER> to confirm <EXIT> to cancel Menu 10-1 R5976483 BARCOSLM R6 17092002...
  • Page 108 10. Programmable Function Keys R5976483 BARCOSLM R6 17092002...
  • Page 109: Standard Source Set Up Files

    5. Fpix MHz: pixel frequency 6. Ftot : total pixels on one horizontal line. 7. Pact: active pixels on one horizontal line. 8. Ltot: total lines in one field 9. Lact: active lines in one field. R5976483 BARCOSLM R6 17092002...
  • Page 110 64,125 1328 1024 SUNXGA70 1024x768 70,041 56,596 74,250 1312 1024 SUNXGA77 1024x768 77,069 62,040 84,375 1360 1024 SUP_MAC 1024x768 60,000 48,780 63,999 1312 1024 SVGA_56V 800x600 56,250 35,156 36,000 1024 SVGA_60V 800x600 60,317 37,879 40,000 1056 R5976483 BARCOSLM R6 17092002...
  • Page 111 1024x768 70,000 57,050 78,044 1368 1024 XGA_70V 1024x768 69,705 56,182 74,610 1328 1024 XGA_72 1024x768 71,955 58,140 80,000 1376 1024 XGA_75 1024x768 75,781 61,080 86,000 1408 1024 XGA75_GS 1024x768 74,534 59,701 79,284 1328 1024 Table A-1 R5976483 BARCOSLM R6 17092002...
  • Page 112 A. Standard Source set up Files R5976483 BARCOSLM R6 17092002...
  • Page 113: Barco Control Manager

    The Barco Control Manager has been successfully tested on Microsoft Windows platform (98/NT 4.0/Windows 2000) with Internet Explorer 4.0. On other platforms and with other browsers, it should run fine when the browser supports Java Applets and supports the Java Swing library.
  • Page 114: Control Manager Start Page

    Information on the Start Up page. The nick name of the projector is shown in the middle of the screen. E.g. default indicated as ’Barco - projector’. Below the loca- tion of the projector, default indicated as ’Location’. This name and location can be replaced by any other name or location, see Configuration window / Settings.
  • Page 115: Control

    Image Enhancement • Lens adjustment • Geometry adjustment • Blanking adjustment B.4.1 Start up Start up To start up the control window : 1. Click on Control. A drop down menu will be displayed. (image B-4) R5976483 BARCOSLM R6 17092002...
  • Page 116: Available Items

    Brightness Color Tint Sharpness Phase Gamma Image enhancement Noise reduction Dynamic Color Dept CTI on/off Decoding ’ebu’ or ’ire’ Lens Zoom Focus Shift Geometry Image Shift Size Aspect Ratio Keystone Correction Blanking Changing the blanking settings R5976483 BARCOSLM R6 17092002...
  • Page 117: General Control

    1. Click on one of the buttons on the content pane. (image B-6) The indicated function can be switched on or off. When the green light in the button lights up, the function is on. Image B-6 Control General window R5976483 BARCOSLM R6 17092002...
  • Page 118: Source

    (image B-8) A value indication for the setting will be given just below the slide bar of the adjustment. Changing a setting will have immediate influence on the displayed image. Image B-8 Image settings R5976483 BARCOSLM R6 17092002...
  • Page 119: Image Enhancement

    The possibility is offered to decode the NTSC video signals via the default American IRE standard or via the European EBU standard. Decoding a NTSC signal using the European EBU standard may result in a greenish tint. B.4.6 Lens adjustment How to change The lens adjustment can be done with lens web page . R5976483 BARCOSLM R6 17092002...
  • Page 120: Geometry Adjustment

    Click once with the mouse on the shift screen and use the cursor keys on the keyboard to shift the image (steps of 1 pixel). The black screen indicates its initial position. The shift values are given in a text box below the shifted image. R5976483 BARCOSLM R6 17092002...
  • Page 121: Blanking Adjustment

    Blanking adjustments affect only the edges of the projected image and are used to frame the projected image on to the screen and to hide or black out unwanted information (or noise). The blanking values are given in a text box below the image. A ’0’ value in the text box indicates no blanking. Image B-12 Blanking adjustment R5976483 BARCOSLM R6 17092002...
  • Page 122: Configuration

    These names will be visible on the Control Source screen. Security When selecting an item in the configuration drop down menu, the security login and password for administrator will be asked(im- age B-5). R5976483 BARCOSLM R6 17092002...
  • Page 123: Mail Set Up

    6. To send an E-mail immediately, click on ’Send now’. Image B-14 Mail configuration Repeat the above steps for the other mail configurations if necessary. B.5.3 Security What can be done The administrator can add or change the advanced user password and the administrator password. R5976483 BARCOSLM R6 17092002...
  • Page 124: Data & Time

    4. Click on apply to activate the new password. B.5.4 Data & Time Internet Protocol. The network layer of TCP/IP. Required for communication with the internet. TCP/IP Transmission Control Protocol/Internet Protocol. The native protocol of the internet. Network time protocol R5976483 BARCOSLM R6 17092002...
  • Page 125: Settings

    Each time the projector is powered down, the date & time settings has to be filled out again when chosen for the second method. B.5.5 Settings What can be done The projector nick name, location, SMTP server address and Lamp warning message time can be filled in. R5976483 BARCOSLM R6 17092002...
  • Page 126: Diagnostics

    1. Click in the Lamp warning text field. 2. Fill out the time a lamp warning message has to be send. B.6 Diagnostics Overview • Start Up • General Status • Job Log • Advanced Diagnostics R5976483 BARCOSLM R6 17092002...
  • Page 127: Start Up

    • current source • run time • lamp life time • software version B.6.3 Job Log Overview The job log screen gives an overview of the last 30 logs stored in the projector. R5976483 BARCOSLM R6 17092002...
  • Page 128: Advanced Diagnostics

    When a warning or error occured, one of the lights in the buttons will be red and the error list for that button will be expand on the right side of the advanced diagnostic screen. The occured error should be indicated by a red light. R5976483 BARCOSLM R6 17092002...
  • Page 129 Revision Sheet Barco nv Events/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70, Fax: +32 56.36.88.24 E-mail: antoon.dejaegher@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5976483/01): page wrong correct R5976483 B SLM R6 17092002 ARCO...

Table of Contents
