To display general statistics:
Select General Statistics from the Main Menu.

Displaying Port Statistics

The Port Statistics display includes the information described in Table 4.3 for one or all ports. All
values are cumulative since the ESP hub was last reset. This display refreshes every five seconds.

Table 4.3: Port Statistics Display

Item
Status
Destination IP Address
Receive Bytes
Transfer Bytes
Signals
Baudrate/Sz/Par/Stp
Frame/Parity/Overrun
To display port statistics:
1. Select Port Statistics from the Main Menu. The Serial Port Selection window will open.
2. Select a port number or all ports, then click Apply.

Displaying Connection Status

The Connection Status display has two sections: Serial Port Active Connection Status and Port
Redirection Connections. This display refreshes every five seconds.
The Serial Port Active Connection Status section includes the information described in Table 4.4
for one or all serial ports.

Table 4.4: Serial Port Active Connection Status Display

Item
Serial Connection Method
Destination IP Address
Description
Port status flags.
IP address of the server that has the port open.
Number of bytes received.
Number of bytes transmitted.
Current value of the RS-232 signals: RTS, CTS, DTR, DSR and CD. A signal is
listed in the display only if it is asserted (high).
Baud rate, data size (5-8 bits), parity (N=none, O=odd, E=even, M=mark or
S=space) and number of stop bits (1 or 2).
Number of framing errors, parity errors and overruns.
Description
Connection method: serial port redirection, Telnet server, TCP server, TCP client,
modem emulation, configuration utility or idle. If a port is idle, no other values will
be displayed.
IP address of the remote server.
Chapter 4: Web Interface 39
