The Compact DECT System
This sections gives a brief overview of the elements within the Compact
DECT system.
Compact DECT Base Station (CDBS)
A CDBS unit supports up to six simultaneous handset calls. Using standard
telephony cable (not supplied) a CDBS can be placed up to 1Km from the
Communications Platform. The CDBS is designed for wall mounting and is
supplied with a plug top PSU fitted with 2 mtrs of cable.
–
–
Repeater
A Repeater works in conjunction with a CDBS to extend that CDBS's area of
coverage. Two versions are available; a standard repeater and one that can
have an optional directional aerial fitted to increase the distance from the
associated CDBS (up to 1km line of sight).
Each Repeater is programmed to associate with a particular CDBS using a
Repeater Setup program. The Repeater can handle up to two simultaneous
calls. These calls are 'borrowed' from the CDBS. Hence, each call routed via
the Repeater reduces the number of calls that the CDBS can handle.
The Repeater does not need any wiring connection to the CDBS. The
Repeater is designed for wall mounting and is supplied with a plug top PSU
fitted with 2 mtrs of cable.
Size:
Power: Power from a 230V, 50Hz plug top PSU, (9VDC, 300mA).
20DT Handset
Each handset is supplied with a battery.
–
–
–
Note: A label, located beneath the battery pack, provides both the handset
Single Chargers
The single chargers are designed as a free-standing desk units.
The single chargers are supplied with a mains power supply unit appropriate
to the ordering country.
Compact DECT - Installation Manual
38DHB0002UKFH – Issue 5 (27th October 2003)
Size:
165mm wide x 165 high x 50mm deep.
Power:
Power from a 230V, 50Hz plug top PSU, (9VDC, 0.6A).
100mm wide x 100 high x 40mm deep (inc. wall mounting bracket).
121g ±10g (including battery).
Weight:
Size:
143mm x 48mm x 26mm.
Power:
Fully charged battery; 10 hours speech, 90 hours standby.
Full battery recharge, 3.5 hours in handset charging slot.
registration number and the software level (at time of manufacture).
Alternatively, on latter models, you do not have to remove the back
cover. Simply key *999*84* and press
the battery disconnected. Ensure that the battery is connected before
use.
Introduction - Page 5
. Handsets are supplied with
The Compact DECT System
Page 5
