Performing the Survey

Position the Survey Base Station in the potential position for a base station
installation. Connect the power supply. If possible, also connect an audio
source via either the telephone line or audio jack sockets.
1. With a subscribed handset on-hook, dial *99981* and press ENTER.
2. The handset display shows the signal quality.
3. Take the handset off-hook as this will ensure more realistic figures.
4. Check the boundaries of the Survey Base Stations coverage where Q52
5. Where Repeaters are to be used, repeat the above process (see page 19
6. To return the handset to normal operation, press and hold < until you
Page 10
Using the Site Survey Kit
RPN: 01 <Base station number.
Q52: 52 <Speech quality.
RSSI: 64 <Signal strength.
– If you have connected an audio source you will hear it whilst off-hook.
Use this facility to check the audio quality (only one handset can be
off-hook and receive the audio source at any time).
is greater than 52 and RSSI is greater than 64. Mark this area on the
building plans for all areas that the CDBS might have to serve.
for CDBS/Repeater overlap).
hear a short bleep.
