Sip T1: RFC 3261 T1 value (RTT Estimate). Range: 0 – 64 sec
�
� Sip T2: RFC 3261 T2 value (Maximum retransmit interval for non-INVITE requests and
INVITE responses). Range: 0 – 64 sec
� Sip T4: RFC 3261 T4 value (Maximum duration a message will remain in the network). Range:
0 – 64 sec
� Reg Retry Intvl: Interval to wait before the phone retries registration again after encountering
a failure condition during last registration
� Sub Retry Intvl: Interval to wait before the phone retries registration again after
encountering a failure condition during last registration.
� � � � RTP RTP RTP RTP Parameters Parameters Parameters Parameters
� RTP Port Min: Minimum port number for RTP transmission and reception. <RTP Port Min> and
<RTP Port Max> should define a range that contains at least 2 even number ports . Defaults
to 16384
� RTP Port Max: Maximum port number for RTP transmission and reception. <RTP port Min>
and <RTP Port Max> should define a range that contains at least 2 even number ports.
Defaults to 16482.
� RTP Packet Size(ms): Packet size in milliseconds, which can be 10, 20, 30, 40, 60.
� � � � SDP SDP SDP SDP Payload Payload Types Payload Payload Types Types Types
� The configured dynamic payloads are used for outbound calls only where the SPA presents
