webpage.
� Admin password: set admin webpage access password.(username:admin)
� User password: set user webpage access password.(username:user)
� HTTP port: set port for HTTP(default is 80)
For example, the AT840's ip is 192.168.1.223
HTTP port was set as 100, you have to type "http://192.168.1.223:100" in web browser to
enter AT840 webpage.
� � � � VPN VPN
VPN VPN
� VPN Enable: whether enable VPN
� VPN Type: only support L2TP VPN
Server address: VPN server address
�
� Username: VPN account's username
� Password: VPN account's password
After apply, the phone will reboot. The VPN ip will show on the System Status page.
� � � � VLAN VLAN VLAN VLAN
� Use Vlan Tagging: vlan tag or untag
� Voice VLAN Identifier(1..4094) : Assign VLAN id for voice stream between 1 to 4094
� Voice VLAN Priority : the degree is 0-7, 7 is the highest priority.
� Data VLAN Identifier(1..4094) : Assign VLAN id for data stream between 1 to 4094
� Data VLAN Priority : the degree is 0-7, 7 is the highest priority.
Port Link
� � � � Port Port Port Link Link Link
