AMS Installation Options

1. Following are some examples of ways you can incorporate AMS into your network and
RAID systems.
Home-based PC
+ Monitoring Utility
A networked PC
+ Monitoring Utility
PC
+ WD SATA RAID Controller
+ Message Agent
Internet
Modem
Router & Firewall
Company LAN
PC
+ WD SATA RAID Controller
+ Internal RAID array
+ Message Agent
Figure 1. LAN and Internet Connections
WD ARRAY MANAGEMENT SETUP
USER MANUAL
Laptop computer
+ Monitoring Utility
Network File Server
+ Message Serv er
PC
+ WD SATA RAID Controller
+ Message Agent
