Toolbar

The Toolbar is a series of buttons that are shortcuts to performing specific tasks. You will
never see all buttons active as in the example below.
They become active when you click on specific system components in Tree View. Only the
tool buttons pertaining to that component are active.
Most of these functions require User Account Rights. These are specified when a User is
added or modified. Following is a description of the Toolbar buttons:
New Server. Available when you select the MyConsole
Creates a new Message Server.
Connect. Available when you select the Message Server
Initiates a connection with the RAID Server.
Disconnect. Available when you select a Message Server
the RAID Server. Used when you want to shut down a RAID server for repair.
Delete User. Available when you select a User
monitoring and alert access.
New User. Available when you select the User Management
About. Brings up the information about this version of AMS.
Help. Always available. Brings up the Online Help.

Popup Menus

In addition to the commands in the dropdown menus, there is a corresponding set of
commands you can access via popup menus.
In a popup menu, you can use any of the commands that are in black.
You will notice that some functions are grayed out, meaning that you cannot use them.
Many functions require that you have User Account Rights to perform them.
My Console Icon
Right-click on the My Console
New Server (Remote AMS)
!
Screen refresh
!
Rename the My Console icon
!
Figure 28. The Toolbar
icon. Deletes the user from
icon to access the following commands:
WD ARRAY MANAGEMENT SETUP
USER MANUAL
icon in Remote AMS.
icon in Remote AMS.
icon. Disconnects from
icon.
