Delete An Array - Western Digital Array Management Setup User Manual

On Demand Synchronization
In addition to schedule Synchronization, you can direct the WD SATA RAID Controller to
begin the Synchronization process immediately. To access this feature:
1. Right-click on the Array View
2. Click OK to the confirmation message.
Information View displays the progress (below).
During the Synchronization, the array will be available for use but it may run noticeably
slower.
If the popup messages are enabled, one will notify you when the Synchronization is
successfully completed. The array will return to Functional status.
Stop, Pause, Continue
WD recommends that you let your rebuild run to completion. If you need to pause the
process:
1. Right-click on the Array View
from the popup menu.
2. To continue, right-click on the same icon again and select Continue from the popup
menu.

Delete an Array

To delete an array:
1. Right-click on the Array View
2. Select Delete from the popup menu.
3. Click OK in the confirmation dialog box.
icon and select Synchronize from the popup menu.
icon of the Array that is rebuilding and select Pause
icon of the Array you want to delete.
CHAPTER 5: RAID MONITORING AND MAINTENANCE WITH AMS - 55
WD ARRAY MANAGEMENT SETUP
USER MANUAL
