Western Digital Array Management Setup User Manual page 37

Disconnect from RAID Server
Log out of the RAID Server effectively logs you out of all RAID PCs using that network
connection.
To disconnect from the network:
• Right-click on a RAID Server
Future Connections to RAID Server
The RAID Server remains under the My Console icon until deleted. It continues to work as
long as the IP address is correct.
To make a connection with an existing RAID Server:
• Right-click on a RAID Server
• Or right-click on the RAID Server icon and click the Connect
The Login list of networked RAID PCs appears as before.
Log into a RAID PC as described above.
icon and select Disconnect from the popup menu.
icon and select Connect from the popup menu.
Figure 33. List of networked RAID PCs
CHAPTER 5: RAID MONITORING AND MAINTENANCE WITH AMS - 33
WD ARRAY MANAGEMENT SETUP
USER MANUAL
icon in the Toolbar.
