2. Click on the RAID Server
computer where the Message Server Software is installed.
If the Message Server software in installed on the monitoring PC (the PC you are now
working on), you can use the default 127.0.0.1 IP address.
3. Click Commit. A list of networked RAID PCs appears as shown below.
Login to RAID PC
1. Right-click on the RAID Machine icon
menu. The Login dialog box appears.
2. In the Login dialog box, type your Username and Password, and click OK.
Initially, administrator is the only user. Use the administrator's password selected during
installation.
3. If you want to log in to another user's RAID PC, obtain the User name and Password if
necessary.
Log Out of RAID PC
You can log out of one RAID PC while remaining connected to others on the network.
Right-click on the RAID Machine
Logout from the popup menu.
icon. In Information View, type in the IP address of the
Figure 31. List of Networked RAID PCs
in Tree View. Select Login from the popup
Figure 32. Login Dialog Box
icon of the PC you want to disconnect and select
