© 2011, Moog Videolarm, Inc. All Rights Reserved
P F D 7 5 C F 2 N
Outdoor Pressurized Fixed Network FusionDome™
Installation and Operation Instructions for the following models:
PFDW75CF2N
IP Network Ready 7" Outdoor pressurized dome housing with WM20G
gooseneck wall mount, with 24VAac input, heater/blower, for an FIXED camera,
120- 24Vac, 96vA transformer, clear dome
PFDW75TF2N
IP Network Ready 7" Outdoor pressurized dome housing with WM20G gooseneck
wall mount, with 24Vac input, heater/blower, for an FIXED camera,
120- 24Vac, 96vA transformer, tinted dome
Before attempting to connect or operate this product, please read these instructions completely.
www.videolarm.com
81-IN5369
02-01-2012
Advertisement
Table of Contents
Related Manuals for Moog Videolarm PFD75CF2N SERIES
Summary of Contents for Moog Videolarm PFD75CF2N SERIES
- Page 1 © 2011, Moog Videolarm, Inc. All Rights Reserved P F D 7 5 C F 2 N Outdoor Pressurized Fixed Network FusionDome™ www.videolarm.com Installation and Operation Instructions for the following models: PFDW75CF2N IP Network Ready 7” Outdoor pressurized dome housing with WM20G gooseneck wall mount, with 24VAac input, heater/blower, for an FIXED camera, 120- 24Vac, 96vA transformer, clear dome PFDW75TF2N IP Network Ready 7” Outdoor pressurized dome housing with WM20G gooseneck wall mount, with 24Vac input, heater/blower, for an FIXED camera, 120- 24Vac, 96vA transformer, tinted dome 81-IN5369 Before attempting to connect or operate this product, please read these instructions completely.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. Keep these instructions. CAUTION Heed all warnings RISK OF ELECTRIC SHOCK DO NOT OPEN Follow all instructions. Do not use this apparatus near water. CAUTION: TO REDUCE THE RISK OF Clean only with damp cloth. ELECTRIC SHOCK, DO NOT REMOVE COVER ( OR BACK). -
Page 3: Terms And Conditions
If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation of the claim shall be given promptly by Purchaser to Moog Videolarm. All claims for warranty service must be made within the warranty period. -
Page 4: Electrical Specifications
Electrical Specifications Contents of Box Power 24VAC PFD75CF2N Class 2 Only 24 VAC 3.3 Amps Total Power: 52 Watts Accessories: Heater: 50 Watts/Blower: 2 Watts Camera Power: 12VDC only; 18 Watts Max Tools Required: .100” Flat Head Screwdriver English Phillips Head Screwdriver 7/16”... - Page 5 Wrap Teflon tape around the pipe threads Securely mount bracket to wall. Pull wiring to ensure a tight seal. through bracket and position grommet as shown. • Con seguridad soporte del montaje a emparedar. Tire del cableado • La cinta del Teflon del abrigo alrededor de la pipa rosca a través del soporte y del ojal de la posición según lo demostrado.
- Page 6 Loop the lanyard over the set screw to Make the appropriate wiring connections temporarily hold housing. from the dome to the pendant. • Coloque el acollador sobre el tornillo de presión para • Hacer las conexiones de cableado de la cúpula de la celebrar temporalmente la cubierta.
- Page 7 26 Watts Wiring the dome can be completed by The beam angle may be adjusted on the These are recommended maximum distances referring to the diagram. for 24VAC with a 10% voltage drop. bottom of the unit. • Atar con alambre la bóveda puede ser terminada •...
- Page 8 Air Chuck Fitting Hose Regulator Nitrogen Tank Hand tighten the screws on the dome. When pressurizing unit be sure to set the Recommended torque 12 inches/lb (1.35Nm). gauge or regulator from 10-20psi (.7-1.4bar). • La mano aprieta los tornillos en la bóveda. Esfuerzo de •...
- Page 9 The beam angle may be adjusted on the After purging check the housing pressure. It Power up the unit. bottom of the unit. should be around 5psi (.34bar). • Después de purgar el cheque la presión de la cubierta. • Energía encima de la unidad. Debe estar alrededor de 5psi (34bar).
-
Page 11: Product Registration/Warranty
Product Registration/Warranty Thank you for choosing Moog Videolarm. We value your patronage and are solely committed to providing you with the highest quality products available and superior customer service. Should a problem arise, rest assure that Moog Videolarm stands behind its products by offering impressive warranty plans: 3 Years on all Housings, Poles, Power Supplies, and Accessories and 5 Years on camera systems (SView, QView, Warriors), and InfraRed Illuminators. Register Your Products Online Take a few moments and validate your purchase via the Online Product Registration Form at www.videolarm.com/productregistration.jsp Register your recent Moog Videolarm purchases and benefit from the following: • Simple and Trouble-Free RMA process • Added into customer database to receive product updates / news • Eliminate the need to archive original purchase documents: Receipts, Purchase Orders, etc…...
