Overview
The Toshiba Net Server supports remote clients over a TCP/IP LAN (and/or WAN). In addition to
running the existing applications, it can also support hundreds of simultaneous desktop
applications.

Net Server Components

Net Server – This is the main program and it manages all of the service sub-components as well
as all of the System-level and Desktop-level client applications. Please refer to the following
diagram to see how all of the components interact.
Level2 PBX Service
Voice Assistant Service
(IVR)
Other Services and
Applications
Other Services and
Applications
PC with desktop client
applications
Figure 1
Net Server System Diagram
Net Server Installation Guide 10/06
Server PC and Software
TCP/IP
LAN / WAN
TCP/IP
Telephone
PC with desktop client
applications
Dialogic DNA Driver
Ethernet Card
Dialogic Card
TCP/IP
Telephone
Analog
Station Ports
(Tip/Ring)
Strata CIX
1
1
