TOSHIBA
WinCIX Off-line Programming for Strata CIX
The WinCIX software in conjunction with CIX eManager, enables you to perform Off-line programming
for Strata CIX systems. With WinCIX and eManager loaded on your PC or server, you can make
programming changes without being connected to the Strata CIX. WinCIX emulates the existence of an
operating CIX system on your computer so eManager can backup and save the edited programming data
into a "default.dat" file on your PC. The edited default.dat file can then be copied to a SmartMedia or
Secure Digital (SD) card and restored to a Strata CIX system.
Important!
Release 4 allows you to rename the default .dat file name but not the (.dat) extension name.
(See the last page for file name change rules)
CAUTION!
1. You must check the WinCIX compatibility table (last page) before using particular
versions of WinCIX on the Strata CIX system.
2. Always make a copy of original default.dat files before you open and edit them using
WinCIX. In an emergency situation you may need the original default.dat file to restore
your original data to the CIX system.
Tips and Limitations
1. The Download function of eManager is not supported with WinCIX Off-line programming. You will
get error messages if you attempt to download programs.
2. Real time functions that only apply to an actual CIX (Date, Time of Day, etc.) do not apply to
WinAdmin Off-line programming.
3. When eManager connects to WinCIX Off-line programming, the CIX Release will always show the
WinCIX release number in the System Setup screen and top information bar.
4. Licenses - always show fully licensed processors when viewing the License screen.
WinCIX Minimum PC Requirements
WinCIX must run on the eManager PC so the requirements of the PC are the same as those for WinAdmin.
There are currently four WinCIX executable files. Each WinCIX executable file requires about 15MB of
hard drive space; or they can run from a CD-ROM to save hard drive space.
Toshiba America Information Systems, Inc.
Digital Solutions Division
9740 Irvine Blvd., Irvine, CA 92618-1697 (949) 583-3700
www.telecom.toshiba.com
Strata
Technical Bulletin
CIX
®
TBCIX-0002D
November, 2007
1 of 5

Advertisement

loading

  Summary of Contents for Toshiba Strata CIX WinCIX

  • Page 1 There are currently four WinCIX executable files. Each WinCIX executable file requires about 15MB of hard drive space; or they can run from a CD-ROM to save hard drive space. Toshiba America Information Systems, Inc. Digital Solutions Division 9740 Irvine Blvd., Irvine, CA 92618-1697 (949) 583-3700 1 of 5 www.telecom.toshiba.com...
  • Page 2 November, 2007 CIX eManager Requirements for WinCIX CIX eManager, Version R4.00A24 or higher, is required to use WinCIX to edit CIX release 4.00 system data. Installing and Running WinCIX WinCIX is a self-executable file and does not need to be installed. The executable file can be opened from a CD-ROM, a folder on the hard drive or desktop icon.
  • Page 3 November, 2007 SNMP service to prevent connection problems between WinAdmin and WinCIX. After stopping SNMP service(s), click OK to continue. 3. Select a Region Code: Click the down arrow and highlight a country. The Region Code is the same as country list in Program 915-04.
  • Page 4 November, 2007 7. Click the Connect Now button. eManager should connect to WinCIX and operate exactly as if it were connected to a CIX system. Note In the PC Local Area Connection Property Settings, you may need to set the PC Internet Protocol (TCP/IP) properties to use the following recommended IP address: 192.168.254.251.
  • Page 5 November, 2007 Programming Data File Name Rules for Opening/Restoring “default.dat files” Refer to WinCIX/WinCTX Software Compatibility table below. Strata WinCIX can only be used with certain Strata CIX software versions. You must check the WinCIX compatibility table below before using particular versions of WinCIX on the Strata CIX systems. Important! The following table will be updated with the release of new software.
