Tippmann CUSTOM PRO Owner's Manual page 10

Tuning The RESPONSE
With a screwdriver, turn the Flow Control Adjustor
E
N
TM
G
L
Tuning - Troubleshooting A:
I
If tuning the Response
in the rate of fire, reset the Flow Control as follows:
S
1) With marker properly unloaded (see page 14), begin
H
adjusting rate of fire by turning flow control clockwise
completely. Do not over tighten or damage will occur. In a safe
direction fire 2 to 4 shots. Trigger should become very hard to
pull or even unable to be pulled. If this occurs, the response
trigger system is functioning properly. Go to step 2. If it does
not occur, go to Troubleshooting B.
2) Now while firing in a safe direction with marker still unloaded,
slowly turn the flow control adjustor counterclockwise until
desired rate of fire is achieved.
Tuning - Troubleshooting B:
If the trigger remains easy to pull after adjusting the flow control,
there may be a leak in the system. Double check installation
making sure all fittings are tight and o-rings are properly seated.
If you need to disassemble to check that all fittings are tight
and o-rings are properly seated, do not disassemble this
marker while it is pressurized with air, follow disassembly /
assembly instructions on page 15.
If a problem still exists, call Tippmann
1-800-533-4831.
NOTE: To disable the Response
the universal 90
valve and replace it with the shut off plug.
TM
trigger produces little or no response
0
fitting attached to the power tube/
8
TM Trigger Rate of Fire
counterclockwise to increase
TM
Service Department at
TM
System, remove
rate of fire to the
desired speed.
